熱賣型號
MOS管
快恢復二極管
肖特基二極管
整流二極管
可控硅
PT-IGBT
場效應帶內置快速二極管

MOSFET管				電源系統常用快恢復二極管
型號	Vdss(V)/Id(A)/Rds(on)Ω	封裝		型號	Vdss(V)/IFAV(A)/Trr(ns)	封裝
IXTP170N075T2	75V/170A/0.0054Ω	TO-220		DPG20C200PB	200V/2X10A/35ns	TO-220AB
IXFH340N075T2	75V/340A/0.0032Ω	TO-247		DPG30C200HB	200V/30A/35 ns	TO-247
IXTP60N10T	100V/60A/0.018Ω	TO-220		DPG60C200HB	200V/60A/35 ns	TO-247AD
IXTP80N10T	100V/80A/0.014Ω	TO-220		DPG20C300PN	300V/2X10A/35ns	TO-220F
IXTQ130N10T	100V/130A/0.009Ω	TO-3P		DPG20C300PB	300V/20A/35 ns	TO-220AB
IXTQ170N10P	100V/170A/ 0.0090 Ω	TO-3P		DPG30C300PC	300V/2X15A/35ns	TO-263AB
IXFA180N10T2-TRL	100V/180A/0.0060Ω	TO-263		DPG30C300HB	300V/2X15A/35ns	TO-247AD
IXTQ200N10T	100V/200A/0.0055Ω	TO-3P		DPG20C400PB	400V/2X10A/45ns	TO-220AB
IXFH160N15T2	150V/160A/ 0.0090 Ω	TO-247		DPG60C300HB	300V/2X30A/35ns	TO-247AD
IXFP76N15T2	150V/76A/0.022Ω	TO-220		DPG20C400PN	400V/2X10A/45ns	TO-220F
IXFP110N15T2	150V/110A/0.0130Ω	TO-220		DPG30C400PB	400v/2X15A/45ns	TO-220
IXTQ60N20T	200V/60A/0.04Ω	TO-3P		DPG60C400HB	400V/2X30A/35ns	TO-247AD
IXTQ74N20P	200V/74A/0.034Ω	TO-3P		DPG80C400HB	400V/2X40A/45ns	TO-247
IXTQ96N20P	200V/96A/0.024Ω	TO-3P		DPG30I300PA	300V/30A/35 ns	TO-220AC
IXTQ50N25T	250V/50A/0.06Ω	TO-3P-3		DPG30I400HA	400v/30A/45ns	TO-247
IXTQ76N25T	250V/76A/0.039Ω	TO-3P		DSEI2X121-02A	200V/2X123A/35ns	SOT-227B(模塊）
IXTQ82N25P	250V/82A/0.035Ω	TO-3P		DSEI2X61-06C	600V/2*60A/35NS	SOT-227B(模塊）
IXTK82N25P	250V/82A/0.035Ω	TO-264		DSEI2X61-12B	1200V/2X52A/40ns	SOT-227B(模塊）
IXTK120N25P	250V/120A/0.18Ω	TO-264		DSEI2X101-12A	1200V/2X91A/40ns	SOT-227B(模塊）
IXTQ36N30P	300V/36A/0.11Ω	TO-3P		DSEK60-02A	200V/2X34A/35ns	TO-247AD
IXFP36N30P3	300V/36A/0.110 Ω	TO-220		DSEK60-06A	600V/2X30A/35ns	TO-247
IXTQ52N30P	300V/52A/0.066Ω	TO-3P		DSEC30-06A	600V/2X15A/35ns	TO-247AD
IXTQ69N30P	300V/25A/0.049Ω	TO-3P		DSEC60-06A	600V/2X30A/35ns	TO-247
IXFH86N30T	300V/86A/0.043Ω	TO-247		DSEC16-12AS TR	1200V/20A/40 ns	TO-263AB
IXTQ88N30P	300V/88A/0.04Ω	TO-3P		DHG30I600HA	600V/30A/ 35 ns	TO-247AD
IXFK102N30P	300V/102A/0.033Ω	TO-264		DFE10I600PM	600V/10A/110NS	TO-220F
IXFK140N30P	300V/140A/0.024Ω	TO-264		DSEI60-02A	200V/69A/60ns	TO-247
IXFP16N50P3	500V/16A/0.36Ω	TO-220		DSEI8-06A	600V/8A/35ns	TO-220
IXTQ460P2	500V/24A/0.27Ω	TO-3P		DSEI12-06A	600V/14A/35ns	TO-220AC
IXFH26N50P3	500V/26A/0.23Ω	TO-247		DSEI30-06A	600V/37A/35ns	TO-247
IXFH44N50P	500V/44A/0.14Ω	TO-247AD		DSEI60-06A	600V/60A/35ns	TO-247
IXFH50N50P3	500V/50A/0.125Ω	TO-247		DSEI30-10A	1000V/30A/35ns	TO-247
IXFH52N50P2	500V/52A/0.120Ω	TO-247		DSEI60-10A	1000V/60A/35ns	TO-247
IXTQ480P2	500V/52A/0.12Ω	TO-3P		DSEI12-12A	1200V/11A/50ns	TO-220AC
IXFH60N50P3	500V/60A/0.10Ω	TO-247AD		DSEI30-12A	1200V/26A/40ns	TO-247
IXFX80N50P	500V/80A/0.065 Ω	PLUS247		DSEI60-12A	1200V/52A/40ns	TO-247
IXFK94N50P2	500V/94A/0.068Ω	TO-264		DSEP15-06A/B	600V/15A/35ns/25ns	TO-220
IXFK98N50P3	500V/98A/0.05Ω	TO-264		DSEP29-06A/B	600V/30A/35ns/30ns	TO-220
IXFB132N50P3	500V/132 A/0.039 Ω	PLUS264		DSEP30-06A/B	600V30A/35ns	TO-247
IXFH28N60P3	600V/28A/0.26Ω	TO-247		DSEP60-06A	600V/60A/35ns	TO-247
IXFN80N60P3	600V/66A/ 0.077Ω	SOT-227		DSEP12-12A	1200V/15A/40ns	TO-220AC
IXFK80N60P3	600V/80A/0.07Ω	TO-264		DSEP30-12A	1200V/30A/40ns	TO-247
IXFB110N60P3	600V/110 A/0.056 Ω	PLUS264		DSEP60-12A	1200V/60A/40ns	TO-247
IXFH15N80Q	800V/15A/ 0.60 Ω	TO-247		肖特基二極管
IXFH20N80P	800V/20A/0.52Ω	TO-247		型號	Vdss(V)/Id(A)/	封裝
IXFH24N80P	800V/24A/0.4Ω	TO-247		DSA50C100QB	100V 2*25A	TO-3P
IXFX27N80Q	800V/27A/0.32Ω	PLUS247		DSA20C150PB	150V 2*10A	TO-220
IXFK27N80Q	800V/27A/0.32Ω	TO-264		DSA30C45PB	45V 2*15A	TO-220
IXFK44N80P	800V/44A/0.19Ω	TO-264		DSA30C150PB	150V 2*15A	TO-220
IXFX44N80P	800V/44A/0.19Ω	PLUS247		DSA70C150HB	150V 2*35A	TO-247
IXFK44N80P	800V/44A/0.19Ω	TO-264		DSSK40-008B	80v 2*20A	TO-247
IXFN60N80P	800V/53A/0.14Ω	SOT-227B		DSSK48-003BS	30V 2*25A	TO-263AB
IXFH12N90P	900V/12A/0.90Ω	TO-247		DSSK16-01A	100V 2*8A	TO-220AB
IXFK32N100Q3	1000V/32A/0.320Ω	TO-264		DSSK60-015A	150V 2*30A	TO-247
IXTA2R4N120P	1200V/2.4A/7.50Ω	TO-263		DSSK60-02A	200V 2*30A	TO-247
IXTP3N120	1200V/3A/ 4.5Ω	TO-220		DSSK60-015A	150V 2*30A	TO-247
IXFH12N120P	1200/12A/1.35Ω	TO-247		DSSK80-0008D	8V 2*40A	TO-247
IXFB30N120P	1200V/ 30A/ 0.35 Ω	PLUS264		DSSK80-006B	60V 2*40A	TO-247
				DSA30C200PB	200V 2*15A	TO-220
特別推薦MOSFET				DSSK60-02A	200V 2*30A	TO-247
IXFP22N65X2	650V/22A/0.145Ω	TO-220AB		DSA90C200HB	200V 2*45A	TO-247
IXFH34N65X2	650V/34A/0.100Ω	TO-247		IGBT
IXFH46N65X2	650V/46A/0.069Ω	TO-247	型號	Vdss(V)/IC25℃/IC100℃/VCE(sat)	封裝
IXTH48N65X2	650V/48A/0.065Ω	TO-247	IXXH30N60B3D1	600V / 60A / 30A /1.80	TO-247
IXFH60N65X2	650V/60A/0.052Ω	TO-247	IXGH48N60A3	600/48A/1.35	TO-247
IXFH80N65X2	650V/80A/0.038Ω	TO-247	IXGH48N60C3D1	600V / 75A / 48A/ 2.50	TO-247
IXFH20N85X	850V/20A/.033Ω	TO-247	IXXH50N60B3	600V / 120A/ 50A / 1.80	TO-247
IXFK50N85X	850V/50A/0.105Ω	TO-264	IXGH60N60C3D1	600V / 75A /60A / 2.50	TO-247
整流二極管：			IGBT / MOSFET 驅動IC
型號	Vdss(V)/Id(A)/	封裝	型號	Vdss(V)/Id(A)/Rds(on)Ω	封裝
DSP8-08STRL	800V 8A	TO-263	IX3120G（光藕）	15-30V/2.5A	SOP/DIP8
DSI45-12A	1200V 45A	TO-247	IX4340	5-20V/5A	SOP/DIP8
DSP45-12AZ-TRL	1200V 45A	TO-268	IX4423	4.5~35V/3A	SOP/DIP8
DSI45-16A	1600V 45A	TO-247	IX4424	4.5~35V/3A	SOP/DIP8
DSP45-12A	1200V 45A	TO-247	IX4425	4.5~35V/3A	SOP/DIP8
DSP45-16A	1600V 45A	TO-247	IX4426	4.5~35V/1.5A	SOP/DIP8
UPS電源常用可控硅二極管			IX4427	4.5~35V/1.5A	SOP/DIP/DFN8
型號	V_RRM I_TAV	封裝	IX4428	4.5~35V/1.5A	SOP/DIP/DFN8
MCMA140P1600TA	1600V140A	TO-240	IXDN602	4.5~35V/2A	SOP/DIP-8
CLA50E1200HB	1200V 50A	TO-247AD	IXDN604	4.5~35V/4A	SOP/DIP-8
CLA80E1200HF	1200V/80A	TO-247-3	IXDN604SITR	4.5~35V/4A	SOP-8
CS60-12IO1	1200V 48A	PLUS247	IXDD604SIA	4.5~35V/4A	SOP-8
MCC162-16IO1	1600V 181A	Y4模塊	IXDD609YI	4.5~35V/9A	TO-263AB
CS60-16I01	1600V/48A/0.85V	TO-247-3	IXDN609	4.5~35V/9A	SOP/DIP-8
整流橋			IXDD614YI	4.5~35V/14A	TO-263AB
型號	V_RRM V_VRMS	封裝	IX2113（半橋驅動）	600V/ 2/2A	SOP16/DIP14
GUO40-12NO1	1200V 1300V	GUFP	IXD 602	4.5~35V/2A	SOP/DIP8
GBO25-16NO1	1600V -	GBFP	IXD 604	4.5~35V/4A	SOP/DIP8
VHF36-16IO5	1600V -	FO-F-A	IXD 609	4.5~35V/9A	SOP/DIP
VUO36-16NO8	1600V /500V	FO-B	IXD 614	4.5~35V/14A	SOP/DIP
VBO54-16NO7	1600V 500V	ECO-PAC 1	IXD 630	5~35V/30A	SOP/DIP
VUO82-16NO7	1600V /500V	PWS-D		IXD 630M	5~35V/30A	SOP/DIP

PartNumber	VDSS	ID(cont)	RDS(on)	Ciss	Qg	trr	PD	RthJC	Package
	Max	TC=25°C	Max	Typ	Typ	Typ	(W)	Max	Style
	(V)	(A)	TJ=25°C	(pF)	(nC)	(ns)		(oC/W)
			(?)
IXTQ82N25P	250	82	0.038	4800	142	200	500	0.25	TO-3P
IXTK82N25P	250	82	0.038	4800	142	200	500	0.25	TO-264
IXTK120N25P	250	120	0.024	8700	185	200	700	0.18	TO-264
IXTQ36N30P	300	36	0.11	2250	70	250	300	0.42	TO-3P
IXTQ52N30P	300	52	0.073	3490	110	250	400	0.31	TO-3P
IXTQ69N30P	300	69	0.049	4960	156	330	500	0.25	TO-3P
IXTQ88N30P	300	88	0.04	6300	180	250	600	0.21	TO-3P
IXTQ460P2	500	24	0.27	2890	48	400	480	0.26	TO-3P
IXTQ480P2	500	52	0.12	6800	108	400	960	0.13	TO-3P
IXTQ150N06P	60	150	0.01	3000	118	90	480	0.31	TO-3P
IXTQ200N06P	60	200	0.006	5400	200	90	714	0.21	TO-3P
IXTP75N10P	100	75	0.025	2250	74	120	360	0.42	TO-220
IXTC75N10	100	75	0.02	4500	180	300	230	0.54	ISOPLUS220?
IXTT75N10	100	75	0.02	4500	180	200	300	0.42	TO-268
IXTQ75N10P	100	75	0.025	2250	74	120	360	0.42	TO-3P
IXTH75N10	100	75	0.02	4500	180	300	300	0.42	TO-247
IXTM75N10	100	75	0.02	4500	180	200	300	0.42	TO-204
IXTA75N10P	100	75	0.025	2250	74	120	360	0.42	TO-263
IXTT110N10P	100	110	0.015	3550	110	130	480	0.31	TO-268
IXTQ110N10P	100	110	0.015	3550	110	130	480	0.31	TO-3P
IXTR200N10P	100	120	0.008	7600	235	100	300	0.5	ISOPLUS247?
IXTT140N10P	100	140	0.011	4700	155	120	600	0.25	TO-268
IXTQ140N10P	100	140	0.011	4700	155	120	600	0.25	TO-3P
IXTT170N10P	100	170	0.009	6000	198	120	715	0.21	TO-268
IXTK170N10P	100	170	0.009	6000	198	120	715	0.21	TO-264
IXTQ170N10P	100	170	0.009	6000	198	120	715	0.21	TO-3P
IXTK200N10P	100	200	0.0075	7600	240	100	800	0.18	TO-264
IXTK250N10	100	250	0.005	7800	390	150	730	0.17	TO-264
IXTC62N15P	150	36	0.045	2250	70	150	150	1	ISOPLUS220?
IXTR62N15P	150	36	0.045	2250	70	150	150	1	ISOPLUS247?
IXTH60N15	150	60	0.033	3000	110	150	275	0.45	TO-247
IXTP62N15P	150	62	0.04	2250	70	150	350	0.42	TO-220
IXTA62N15P	150	62	0.04	2250	70	150	350	0.42	TO-263
IXTQ62N15P	150	62	0.04	2250	70	150	350	0.42	TO-3P
IXTT75N15	150	75	-	-	-	-	-	-	TO-268
IXTH75N15	150	75	-	-	-	-	-	-	TO-247
IXTH88N15	150	88	0.022	4800	170	150	400	0.31	TO-247
IXTT88N15	150	88	0.022	4800	170	150	400	0.31	TO-268
IXTK90N15	150	90	0.016	6400	240	300	390	0.3	TO-264
IXTT96N15P	150	96	0.024	3500	110	150	480	0.31	TO-268
IXTQ96N15P	150	96	0.024	3500	110	150	480	0.31	TO-3P
IXTT120N15P	150	120	0.016	4900	150	150	600	0.25	TO-268
IXTQ120N15P	150	120	0.016	4900	150	150	600	0.25	TO-3P
IXTK128N15	150	128	0.015	7000	250	150	540	0.23	TO-264
IXTK150N15P	150	150	0.013	5800	190	150	714	0.21	TO-264
IXTQ150N15P	150	150	0.013	5800	190	150	714	0.21	TO-3P
IXTK180N15	150	180	0.011	-	220	120	800	0.18	TO-264
IXTK180N15P	150	180	0.011	7000	240	150	800	0.18	TO-264
IXTP50N20PM	200	20	0.06	2720	70	150	90	1.66	OVERMOLDED TO-220
IRFP250	200	30	0.085	2970	106	360	190	0.65	TO-247
IXTJ36N20	200	36	0.07	2970	106	200	300	0.65	TO-268 (I3 - PAK)
IRFP260	200	45	0.055	3900	230	260	280	0.45	TO-247
IXTH48N20	200	48	0.05	3000	110	250	275	0.45	TO-247
IXTM50N20	200	50	0.045	-	-	-	-	-	TO-204
IXTQ50N20P	200	50	0.06	2720	70	150	360	0.42	TO-3P
IXTA50N20P	200	50	0.06	2720	70	150	360	0.42	TO-263
IXTH50N20	200	50	0.045	-	-	-	-	-	TO-247
IXTP50N20P	200	50	0.06	2720	70	150	360	0.42	TO-220
IXTT72N20	200	72	0.032	4400	170	200	400	0.31	TO-268
IXTH72N20	200	72	0.032	4400	170	200	400	0.31	TO-247
IXTQ74N20P	200	74	0.034	3300	107	160	480	0.31	TO-3P
IXTT74N20P	200	74	0.034	3300	107	160	480	0.31	TO-268
IXTH96N20P	200	96	0.024	4800	145	160	600	0.25	TO-247
IXTQ96N20P	200	96	0.024	4800	145	160	600	0.25	TO-3P
IXTT96N20P	200	96	0.024	4800	145	160	600	0.25	TO-268
IXTK120N20P	200	120	0.022	6000	152	180	714	0.21	TO-264
IXTQ120N20P	200	120	0.022	6000	152	180	714	0.21	TO-3P
IXTK140N20P	200	140	0.018	7500	240	180	800	0.18	TO-264
IXTK160N20	200	160	0.014	7800	390	250	730	0.17	TO-264
IRFP254	250	23	0.14	2970	106	370	190	0.65	TO-247
IXTR30N25	250	25	0.075	-	-	-	-	-	ISOPLUS247?
IXTH30N25	250	30	0.075	-	-	-	-	-	TO-247
IRFP264	250	38	0.075	4800	-	370	280	0.45	TO-247
IXTH41N25	250	41	0.072	3200	110	300	300	0.42	TO-247
IXTQ42N25P	250	42	0.084	2300	70	200	300	0.42	TO-3P
IXTP42N25P	250	42	0.084	2300	70	200	300	0.42	TO-220
IXTA42N25P	250	42	0.084	2300	70	200	300	0.42	TO-263
IXTH60N25	250	60	0.046	4400	164	300	400	0.31	TO-247
IXTK62N25	250	62	0.035	-	67	-	-	-	TO-264
IXTT64N25P	250	64	0.049	3450	105	200	400	0.31	TO-268
IXTQ64N25P	250	64	0.049	3450	105	200	400	0.31	TO-3P
IXTK80N25	250	80	0.035	6000	240	300	540	0.23	TO-264
IXTT82N25P	250	82	0.038	4800	142	200	500	0.25	TO-268
IXTK100N25P	250	100	0.027	6300	185	200	600	0.21	TO-264
IXTQ100N25P	250	100	0.027	6300	185	200	600	0.21	TO-3P
IXTT100N25P	250	100	0.027	6300	185	200	600	0.21	TO-268
IXTN120N25	250	120	0.02	7700	360	350	730	0.17	SOT-227B
IXTK120N25	250	120	0.018	9400	400	350	560	0.22	TO-264
IXTQ69N30PM	300	25	0.049	4960	156	250	90	1.38	OVERMOLDED
IXTP36N30P	300	36	0.11	2250	70	250	300	0.42	TO-220
IXTA36N30P	300	36	0.11	2250	70	250	300	0.42	TO-263
IXTM40N30	300	40	0.085	-	-	-	-	-	TO-204
IXTH40N30	300	40	0.085	-	-	-	-	-	TO-247
IXTT50N30	300	50	0.065	4400	165	360	400	0.31	TO-268
IXTH50N30	300	50	0.06	4400	165	360	400	0.31	TO-247
IXTT52N30P	300	52	0.073	3490	110	250	400	0.31	TO-268
IXTT69N30P	300	69	0.049	4960	156	330	500	0.25	TO-268
IXTK75N30	300	75	0.045	6000	240	360	540	0.23	TO-264
IXTH88N30P	300	88	0.04	6300	180	250	600	0.21	TO-247
IXTT88N30P	300	88	0.04	6300	180	250	600	0.21	TO-268
IXTK88N30P	300	88	0.04	6300	180	250	600	0.21	TO-264
IXTK102N30P	300	102	0.033	7500	224	250	700	0.18	TO-264
IXTK110N30	300	110	0.025	7800	390	350	730	0.17	TO-264
IXTK140N30P	300	140	0.24	14800	185	250	1040	0.12	TO-264
IRFP360	400	23	0.2	4500	-	420	300	0.45	TO-247
IXTP1R6N50P	500	1.6	6.5	140	3.9	400	43	2.9	TO-220
IXTY1R6N50P	500	1.6	6.5	140	3.9	400	43	2.9	TO-252AA (D PAK)
IXTY2R4N50P	500	2.4	3.75	240	6.1	400	56	2.25	TO-252AA (D PAK)
IXTP2R4N50P	500	2.4	3.75	240	6.1	400	55	2.25	TO-220
IXTP16N50PM	500	7.5	0.42	2480	43	400	75	1.66	OVERMOLDED TO-220
IXTA8N50P	500	8	0.8	1050	20	400	150	0.83	TO-263
IXTP8N50P	500	8	0.8	1050	20	400	150	0.83	TO-220
IXTP12N50P	500	12	0.5	1830	29	-	200	0.62	TO-220
IXTA12N50P	500	12	0.5	1830	29	-	200	0.62	TO-263
IXTC13N50	500	13	0.4	2800	110	600	140	0.9	ISOPLUS220?
IRFP450	500	14	0.4	2800	110	500	190	0.65	TO-247
IXTC26N50P	500	15	0.26	3600	65	400	130	0.95	ISOPLUS220?
IXTH450P2	500	16	0.33	2280	43	400	300	0.42	TO-247
IXTQ16N50P	500	16	0.4	2480	43	400	300	0.42	TO-3P
IXTP16N50P	500	16	0.4	2480	43	400	300	0.42	TO-220
IXTP450P2	500	16	0.33	2280	43	400	300	0.42	TO-220
IXTQ450P2	500	16	0.33	2280	43	400	300	0.42	TO-3P
IXTA16N50P	500	16	0.4	2480	43	400	300	0.42	TO-263
IRFP460	500	20	0.27	4200	135	570	260	0.45	TO-247
IXTM21N50	500	21	0.25	4200	160	600	300	0.42	TO-204
IXTH21N50	500	21	0.25	4200	160	600	300	0.42	TO-247
IXTH22N50P	500	22	0.27	2880	50	400	350	0.35	TO-247
IXTQ22N50P	500	22	0.27	2880	50	400	350	0.35	TO-3P
IXTV22N50PS	500	22	0.27	2880	50	400	350	0.35	PLUS-220 SMD
IXTV22N50P	500	22	0.27	2880	50	400	350	0.35	PLUS-200
IXTH24N50Q	500	24	0.24	3000	82	500	360	0.35	TO-247
IXTH24N50	500	24	0.23	4200	160	600	300	0.42	TO-247
IXTP460P2	500	24	0.27	2890	48	400	480	0.26	TO-220
IXTH460P2	500	24	0.27	2890	48	400	480	0.26	TO-247
IRFP470	500	24	0.23	4200	160	600	300	0.42	TO-247
IXTA460P2	500	24	0.27	2890	48	400	480	0.26	TO-263
IXTM24N50	500	24	0.23	4200	160	600	300	0.42	TO-204
IXTT24N50Q	500	24	0.24	3000	82	500	360	0.35	TO-268
IXTH28N50Q	500	25	0.2	3300	94	500	400	0.31	TO-247
IXTT28N50Q	500	25	0.2	3300	94	500	400	0.31	TO-268
IXTV26N50PS	500	26	0.23	3600	65	300	400	0.31	PLUS-220 SMD
IXTQ26N50P	500	26	0.23	3600	65	300	400	0.31	TO-3P
IXTT26N50P	500	26	0.23	3600	65	300	400	0.31	TO-268
IXTV26N50P	500	26	0.23	3600	65	300	400	0.31	PLUS-200
IXTV30N50PS	500	30	0.2	4150	70	400	460	0.27	PLUS-220 SMD
IXTT30N50P	500	30	0.2	4150	70	400	460	0.27	TO-268
IXTV30N50P	500	30	0.2	4150	70	400	460	0.27	PLUS-200
IXTQ30N50P	500	30	0.2	4150	70	400	460	0.27	TO-3P
IXTH30N50	500	30	0.17	5680	227	850	360	0.35	TO-247
IXTH30N50P	500	30	0.2	4150	70	400	460	0.27	TO-247
IXTK33N50	500	33	0.17	4900	250	850	416	0.3	TO-264
IXTV36N50PS	500	36	0.17	4700	82	400	540	0.23	PLUS-220 SMD
IXTQ36N50P	500	36	0.17	4700	82	400	540	0.23	TO-3P
IXTT36N50P	500	36	0.17	4700	82	400	540	0.23	TO-268
IXTV36N50P	500	36	0.17	4700	82	400	540	0.23	PLUS-200
IXTH36N50P	500	36	0.17	4700	82	400	540	0.23	TO-247
IXTQ40N50Q	500	40	0.14	4550	130	600	500	0.25	TO-3P
IXTQ470P2	500	42	0.145	5400	88	400	830	0.15	TO-3P
IXTQ44N50P	500	44	0.14	5440	98	400	650	0.19	TO-3P
IXTQ24N55Q	550	24	0.27	3000	80	500	400	0.31	TO-3P
IXTU1R4N60P	600	1.4	9	140	5.2	500	50	2.5	TO-251
IXTP1R4N60P	600	1.4	9	140	5.2	500	50	2.5	TO-220
IXTY1R4N60P	600	1.4	9	140	5.2	500	50	2.5	TO-252
IXTY2N60P	600	2	5.1	240	7	400	56	2.25	TO-252AA (D PAK)
IXTP2N60P	600	2	5.1	240	7	400	56	2.25	TO-220
IXTP3N60P	600	3	2.9	411	9.8	500	70	1.8	TO-220
IXTY3N60P	600	3	2.9	411	9.8	500	70	1.8	TO-252AA (D PAK)
IXTA3N60P	600	3	2.9	411	9.8	500	70	1.8	TO-263
IXTA4N60P	600	4	2	635	13	500	90	1.41	TO-263
IXTU4N60P	600	4	2	635	13	500	90	1.41	TO-251
IXTP7N60PM	600	4	1.1	1180	20	500	41	3	OVERMOLDED TO-220
IXTY4N60P	600	4	2	635	13	500	90	1.41	TO-252
IXTP4N60P	600	4	2	635	13	500	90	1.41	TO-220
IXTP5N60P	600	5	1.7	750	14.2	500	100	1.25	TO-220
IXTP10N60PM	600	5	0.74	1610	32	500	50	2.5	OVERMOLDED TO-220
IXTA5N60P	600	5	1.7	750	14.2	500	100	1.25	TO-263
IXTA7N60P	600	7	1.1	1080	20	500	150	0.83	TO-263
IXTP7N60P	600	7	1.1	1080	20	500	150	0.83	TO-220
IXTP14N60PM	600	7	0.55	2500	36	500	75	1.66	Overmolded TO-220
IXTP18N60PM	600	9	0.42	2500	50	500	90	1.39	OVERMOLDED TO-220
IXTP10N60P	600	10	0.74	1720	32	500	200	0.62	TO-220
IXTA10N60P	600	10	0.74	1720	32	500	200	0.62	TO-263
IXTA14N60P	600	14	0.55	2500	36	500	300	0.42	TO-263
IXTP14N60P	600	14	0.55	2500	36	500	300	0.42	TO-220
IXTQ14N60P	600	14	0.55	2500	36	500	300	0.42	TO-3P
IXTV18N60P	600	18	0.42	2500	49	500	360	0.35	PLUS-200
IXTV18N60PS	600	18	0.42	2500	49	500	360	0.35	PLUS-220 SMD
IXTQ18N60P	600	18	0.42	2500	49	500	360	0.35	TO-3P
IXTH20N60	600	20	0.35	4500	150	600	300	0.42	TO-247
IXTM20N60	600	20	0.35	4500	150	600	300	0.42	TO-204
IXTQ22N60P	600	22	0.35	3600	62	500	400	0.31	TO-3P
IXTV22N60PS	600	22	0.35	3600	62	500	400	0.31	PLUS-220 SMD
IXTV22N60P	600	22	0.35	3600	62	500	400	0.31	PLUS-200
IXTQ23N60Q	600	23	0.32	3300	90	500	400	0.31	TO-3P
IXTT26N60P	600	26	0.27	4150	72	500	460	0.27	TO-268
IXTH26N60P	600	26	0.27	4150	72	500	460	0.27	TO-247
IXTV26N60P	600	26	0.27	4150	72	500	460	0.27	PLUS-200
IXTQ26N60P	600	26	0.27	4150	72	500	460	0.27	TO-3P
IXTV26N60PS	600	26	0.27	4150	72	500	460	0.27	PLUS-220 SMD
IXTH30N60P	600	30	0.24	5050	82	500	540	0.23	TO-247
IXTT30N60P	600	30	0.24	5050	82	500	540	0.23	TO-268
IXTV30N60PS	600	30	0.24	5050	82	500	540	0.23	PLUS-220 SMD
IXTQ30N60P	600	30	0.24	5050	82	500	540	0.23	TO-3P
IXTV30N60P	600	30	0.24	5050	82	500	540	0.23	PLUS-200
IXTY01N80	800	0.1	50	60	8	1500	25	3	TO-252AA (D PAK)
IXTU01N80	800	0.1	50	60	8	1500	25	3	TO-251
IXTU1N80P	800	1	14	250	9	700	42	3	TO-251
IXTA1N80	800	1	11	220	8.5	710	40	3.1	TO-263
IXTA1N80P	800	1	14	250	9	700	42	3	TO-263
IXTY1N80P	800	1	14	250	9	700	42	3	TO-252
IXTP1N80	800	1	11	220	8.5	710	40	3.1	TO-220
IXTP1N80P	800	1	14	250	9	700	42	3	TO-220
IXTY1N80	800	1	11	220	8.5	710	40	3.1	TO-252AA (D PAK)
IXTP2N80	800	2	6.2	440	22	510	54	2.3	TO-220
IXTY2N80P	800	2	6	440	10.6	650	70	1.8	TO-252AA (D PAK)
IXTA2N80P	800	2	6	440	10.6	650	70	1.8	TO-263
IXTU2N80P	800	2	6	440	10.6	650	70	1.8	TO-251
IXTA2N80	800	2	6.2	440	22	510	54	2.3	TO-263
IXTP2N80P	800	2	6	440	10.6	650	70	1.8	TO-220
IXTA4N80P	800	3.5	3	750	15	600	100	1.25	TO-263
IXTP4N80P	800	3.5	3	750	15	600	100	1.25	TO-220
IXTH6N80A	800	6	1.4	-	-	-	-	-	TO-247
IXTH13N80	800	13	0.8	4500	145	800	300	0.42	TO-247
IXTM13N80	800	13	0.8	4500	145	800	300	0.42	TO-204
IXTH14N80	800	14	0.7	4500	145	800	300	0.42	TO-247
IXTH6N90A	900	6	1.4	2600	88	900	180	0.7	TO-247
IXTH6N90	900	6	1.8	2600	88	900	180	0.7	TO-247
IXTM6N90	900	6	1.8	2600	88	900	180	0.7	TO-204
IXTM6N90A	900	6	1.4	2600	88	900	180	0.7	TO-204
IXTH12N90	900	12	0.9	4500	145	900	300	0.42	TO-247
IXTM12N90	900	12	0.9	4500	145	900	300	0.42	TO-204
IXTY01N100	1000	0.1	80	60	8	1500	25	3	TO-252AA (D PAK)
IXTU01N100	1000	0.1	80	60	8	1500	25	3	TO-251
IXTA05N100P	1000	0.5	30	196	8.1	750	50	2.5	TO-263
IXTP05N100P	1000	0.5	30	196	8.1	750	50	2.5	TO-220
IXTP05N100M	1000	0.7	17	260	7.8	710	25	5	OVERMOLDED TO-220
IXTU05N100	1000	0.75	17	260	7.8	710	40	3.1	TO-251
IXTA05N100	1000	0.75	17	260	7.8	710	40	3.1	TO-263
IXTP05N100	1000	0.75	17	260	7.8	710	40	3.1	TO-220
IXTA05N100HV	1000	0.75	17	260	7.8	710	40	3.1	TO-263HV
IXTY05N100	1000	0.75	17	260	7.8	710	40	3.1	TO-252
IXTA08N100P	1000	0.8	20	240	11.3	750	42	3	TO-263
IXTP08N100P	1000	0.8	20	240	11.3	750	42	3	TO-220
IXTY08N100P	1000	0.8	20	240	11.3	750	42	3	TO-252
IXTY1N100P	1000	1	15	331	15.5	750	50	2.5	TO-252
IXTP1N100P	1000	1	15	331	15.5	750	50	2.5	TO-220
IXTA1N100P	1000	1	15	331	15.5	750	50	2.5	TO-263
IXTP1R4N100P	1000	1.4	11	450	17.8	750	63	2	TO-220
IXTA1R4N100P	1000	1.4	11	666	17.8	750	63	2	TO-263
IXTY1R4N100P	1000	1.4	11	450	17.8	750	63	2	TO-252
IXTP1N100	1000	1.5	11	480	23	710	54	2.3	TO-220
IXTH1N100	1000	1.5	11	480	23	710	60	2.3	TO-247
IXTT1N100	1000	1.5	11	480	23	710	60	2.3	TO-268
IXTA1N100	1000	1.5	11	480	23	710	54	2.3	TO-263
IXTA2N100P	1000	2	7.5	655	24.3	800	86	1.45	TO-263
IXTP2N100	1000	2	7	825	18	800	100	1.25	TO-220
IXTY2N100P	1000	2	7.5	655	24.3	800	86	1.45	TO-252
IXTP2N100P	1000	2	7.5	655	24.3	800	86	1.45	TO-220
IXTA2N100	1000	2	7	825	18	800	100	1.25	TO-263
IXTP3N100P	1000	3	4.8	1100	39	820	125	1	TO-220
IXTH3N100P	1000	3	4.8	1100	39	820	125	1	TO-247
IXTA3N100P	1000	3	4.8	1100	39	820	125	1	TO-263
IXTH5N100A	1000	5	2	2600	88	900	180	0.7	TO-247
IXTM5N100A	1000	5	2	2600	88	900	180	0.7	TO-204
IXTM12N100	1000	12	1.05	4000	150	1000	300	0.42	TO-204
IXTH12N100	1000	12	1.05	4000	150	1000	300	0.42	TO-247
IXTH12N100Q	1000	12	1.05	3000	95	740	300	0.42	TO-247
IXTH14N100	1000	14	0.82	5650	195	850	360	0.35	TO-247
IXTX24N100	1000	24	0.4	8700	267	850	568	0.22	PLUS247
IXTP3N110	1100	3	4	1050	39	700	150	0.8	TO-220
IXTA3N110	1100	3	4	1050	39	700	150	0.8	TO-263
IXTH13N110	1100	13	0.92	5650	195	850	360	0.35	TO-247
IXTP02N120P	1200	0.2	75	104	4.7	1600	33	3.8	TO-220
IXTY02N120P	1200	0.2	75	104	4.7	1600	33	3.8	TO-252
IXTP06N120P	1200	0.6	34	236	13.3	900	42	3	TO-220
IXTA06N120P	1200	0.6	34	236	13.3	900	42	3	TO-263
IXTA08N120P	1200	0.8	25	333	14	900	50	2.5	TO-263
IXTP08N120P	1200	0.8	25	333	14	900	50	2.5	TO-220
IXTP1N120P	1200	1	20	445	17.6	900	63	2	TO-220
IXTY1N120P	1200	1	20	445	17.6	900	63	2	TO-252
IXTA1N120P	1200	1	20	445	17.6	900	63	2	TO-263
IXTY1R4N120P	1200	1.4	13	666	24.8	900	86	1.45	TO-252
IXTP1R4N120P	1200	1.4	13	666	24.8	900	86	1.45	TO-220
IXTY1R4N120PHV	1200	1.4	13	666	24.8	900	86	1.45	TO-252
IXTA1R4N120P	1200	1.4	13	666	24.8	900	86	1.45	TO-263
IXTH2R4N120P	1200	2.4	7.5	1207	37	920	125	1	TO-247
IXTA2R4N120P	1200	2.4	7.5	1207	37	920	125	1	TO-263
IXTP2R4N120P	1200	2.4	7.5	1207	37	920	125	1	TO-220
IXTP3N120	1200	3	4.5	1100	42	700	200	0.62	TO-220
IXTA3N120	1200	3	4.5	1100	42	700	200	0.62	TO-263
IXTH3N120	1200	3	4.5	1100	42	700	200	0.62	TO-247
IXTA3N120HV	1200	3	4.5	1100	42	700	200	0.62	TO-263HV
IXTH6N120	1200	6	2.4	1950	56	850	300	0.42	TO-247
IXTT6N120	1200	6	2.4	1950	56	850	300	0.42	TO-268
IXTH12N120	1200	12	1.4	3400	95	850	460	0.27	TO-247
IXTT12N140	1400	12	2	3720	106	1200	890	0.14	TO-268
IXTH12N140	1400	12	2	3720	106	1200	890	0.14
IXTX20N140	1400	20	1	7800	215	1100	1250	0.1	PLUS247
IXTK20N140	1400	20	1	7800	215	1100	1250	0.1	TO-264
IXTQ3N150M	1500	1.83	7.3	1375	38.6	900	73	1.7	OVERMOLDED TO-3P
IXTH2N150	1500	2	9.2	830	28	377	170	0.73	TO-247
IXTJ3N150	1500	2.3	8	1375	38.6	900	110	1.13	ISO TO-247
IXTJ4N150	1500	2.5	6	1576	44.5	900	110	1.13	ISO TO-247
IXTJ6N150	1500	3	3.85	2230	67	1500	125	1	ISO TO-247
IXTA3N150HV	1500	3	7.3	1375	38.6	900	250	0.5	TO-263
IXTH3N150	1500	3	7.3	1375	38.6	900	250	0.5	TO-247
IXTT4N150HV	1500	4	6	1576	44.5	900	280	0.45	TO-268HV
IXTH4N150	1500	4	6	1576	44.5	900	280	0.45	TO-247
IXTA4N150HV	1500	4	6	1576	44.5	900	280	0.45	TO-263
IXTH6N150	1500	6	3.5	2230	67	1500	540	0.23	TO-247
IXTT6N150	1500	6	3.5	2230	67	1500	540	0.23	TO-268
IXTT12N150	1500	12	2.2	3720	106	1200	890	0.14	TO-268
IXTT12N150HV	1500	12	2.2	3720	106	1200	890	0.14	TO-268HV
IXTH12N150	1500	12	2.2	3720	106	1200	890	0.14	TO-247
IXTK20N150	1500	20	1	7800	215	1100	1250	0.1	TO-264
IXTX20N150	1500	20	1	7800	215	1100	1250	0.1	PLUS247
IXTA1N200P3HV	2000	1	40	646	23.5	2300	125	1	TO-263HV
IXTH1N200P3HV	2000	1	40	646	23.5	2300	125	1	TO-247HV
IXTH1N200P3	2000	1	40	646	23.5	2300	125	1	TO-247
IXTH3N200P3HV	2000	3	5	1860	70	420	520	0.24	TO-247HV
IXTT3N200P3HV	2000	3	8	1860	70	420	520	0.24	TO-268-HV
IXTF6N200P3	2000	4	4.2	3700	143	520	215	0.58	ISOPLUS i4-Pak?
IXTX6N200P3HV	2000	6	4	3700	143	520	960	0.13	TO-247PLUS-HV
IXTH06N220P3HV	2200	0.6	80	290	10.4	1100	104	1.2	TO-247HV
IXTH1R8N220P3HV	2200	1.8	21.5	965	31	1300	194	0.64	TO-247HV
IXTA02N250HV	2500	0.2	450	116	7.4	1500	83	1.5	TO-263AB
IXTV02N250S	2500	0.2	450	116	7.4	1500	83	1.5	PLUS220SMD
IXTH02N250	2500	0.2	450	116	7.4	1500	83	1.5	TO-247
IXTH05N250P3HV	2500	0.5	110	303	10.5	1200	104	1.2	TO-247HV
IXTF1N250	2500	1	40	1660	41	2500	110	1.13	ISOPLUS i4-Pak?
IXTH1R4N250P3	2500	1.4	28	960	33	1800	195	0.64	TO-247
IXTH1N250	2500	1.5	40	1660	41	2500	250	0.5	TO-247
IXTT1N250HV	2500	1.5	40	1660	41	2500	250	0.5	TO-268HV
IXTK5N250	2500	5	8.8	8560	200	1200	960	0.13	TO-264
IXTX5N250	2500	5	8.8	8560	200	1200	960	0.13	PLUS247
IXTN5N250	2500	5	8.8	8560	200	1200	700	0.18	SOT-227
IXTH04N300P3HV	3000	0.4	190	283	13	1100	104	1.2	TO-247HV
IXTH1N300P3HV	3000	1	50	895	30.6	1800	195	0.64	TO-247HV
IXTT1N300P3HV	3000	1	50	895	30.6	1800	195	0.64	TO-268HV
IXTF2N300P3	3000	1.6	21	1890	73	400	160	0.77	ISOPLUS i4-Pak?
IXTT2N300P3HV	3000	2	21	1890	73	400	520	0.24	TO-268HV
IXTH2N300P3HV	3000	2	21	1890	73	400	520	0.24	TO-247HV
IXTX4N300P3HV	3000	4	12.5	3680	139	420	960	0.13	TO-247PLUS-HV
IXTV03N400S	4000	0.3	290	435	16.3	2800	130	0.96	PLUS220SMD
IXTF03N400	4000	0.3	300	435	16.3	2800	70	1.78	ISOPLUS i4-Pak?
IXTH03N400	4000	0.3	290	435	16.3	2800	130	0.96	TO-247
IXTF1N400	4000	1	60	2530	78	3500	160	0.78	ISOPLUS i4-Pak?
IXTF02N450	4500	0.2	625	246	10.6	1600	78	1.6	ISOPLUS i4-Pak?
IXTT02N450HV	4500	0.2	625	246	10.6	1600	113	1.1	TO-268HV
IXTH02N450HV	4500	0.2	625	246	10.6	1600	113	1.1	TO-247HV
IXTF1N450	4500	0.9	80	1700	46	1750	165	0.77	ISOPLUS i4-Pak?
IXTT1N450HV	4500	1	80	1700	46	1750	520	0.24	TO-268HV
IXTH1N450HV	4500	1	80	1700	46	1750	520	0.24	TO-247
IXTF1R4N450	4500	1.4	40	3300	88	660	190	0.65	ISOPLUS I4-PAK
IXTX1R4N450HV	4500	1.4	40	3300	88	660	960	0.13	TO-247PLUS-HV
IXTL2N450	4500	2	20	6860	180	1750	220	0.56	ISOPLUS i5-Pak?
IXTL2N470	4700	2	20	6860	180	1750	220	0.56	ISOPLUS i5-Pak

PartNumber	VRRM	IFAVM	IFAVM	@TC	IFRMS	IFSM	VF	@IF	trr	IRM	@-di/dt	TVJM	RthJC	Package
	(V)	d=0.5	d=0.5	(°C)	(A)	10ms	max	(A)	typ	typ	(A/μs)	(°C)	max	Style
		Total	PerDiode			TVJ=45°C	TVJ=150°C		TVJ=25°C	TVJ=100°C			(K/W)
		(A)	(A)			(A)	(V)		(ns)	(A)
DSEK60-02A	200	68	34	115	50	325	0.85	30	35	4	100	150	1	TO-247
DSEI2x121-02A	200	246	123	70	150	1200	0.95	120	35	12	200	150	0.5	SOT-227B
DPG60C400HB	400	60	30	135	70	360	1.13	30	45	8.5	200	175	0.95	TO-247
DSEP15-06A	600	15	15	140	35	110	1.35	15	35	7	200	175	1.6	TO-220AC
DSEP29-06A	600	30	30	135	35	250	1.26	30	35	10	200	175	0.9	TO-220AC
DSEC60-06A	600	60	30	135	70	250	1.25	30	35	10	100	175	0.9	TO-247AD
DSEK60-06A	600	60	30	85	50	300	1.4	37	35	10	240	150	1	TO-247
DSEI60-10A	1000	60	60	60	100	500	1.8	60	35	32	480	150	0.66	TO-247
DSEP12-12A	1200	12	12	135	-	90	1.87	15	40	9	200	175	1.6	TO-220AC
DSEI60-12A	1200	52	52	60	100	500	1.65	60	40	32	480	150	0.66	TO-247
DPG10I200PA	200	10	10	145	35	140	0.98	10	35	5.5	200	175	2.3	TO-220AC
DPG10I200PM	200	10	10	125	35	140	0.98	10	35	5.5	200	175	4.4	TO-220ACFP
DPG15I200PA	200	15	15	140	35	240	1.01	15	35	6.5	200	175	1.7	TO-220AC
DPG20C200PB	200	20	10	150	35	140	0.98	10	35	5.5	200	175	2.3	TO-220AB
DPG20C200PN	200	20	10	125	35	140	0.98	10	35	5.5	200	175	4.4	TO-220ABFP
DPG30C200HB	200	30	15	145	70	250	1	15	35	6.5	200	175	1.7	TO-247
DPG30C200PC	200	30	15	145	35	240	1.01	15	35	6.5	200	175	1.7	TO-263AB
DPG30C200PB	200	30	15	145	35	240	1.01	15	35	6.5	200	175	1.7	TO-220AB
DPG60C200QB	200	60	30	140	70	360	1.06	30	35	7	200	175	0.95	TO-3P
DPG60C200HB	200	60	30	140	70	360	1.06	30	35	7	200	175	0.95	TO-247
DPF60I200HA	200	60	60	140	-	550	0.9	60	45	10	200	175	0.55	TO-247AD
DPF60C200HB	200	60	30	150	-	400	0.91	30	55	10	200	175	0.95	TO-247 AD
DSEK60-02AR	200	68	34	85	50	325	0.85	30	35	4	100	150	1	ISOPLUS247?
DSEI60-02A	200	69	69	85	98	600	0.88	60	35	8	200	150	0.75	TO-247
DPF80C200HB	200	80	40	140	70	560	0.95	40	55	11	200	175	0.7	TO-247AD
DSEI2x61-02A	200	142	71	85	100	950	0.88	60	35	8	200	150	0.8	SOT-227B
DSEI2x161-02P	200	330	165	70	270	1200	1.2	200	35	20	200	150	0.29	ECO-PAC 2
DPF240X200NA	240	240	120	80	150	1200	1.06	120	55	16	200	150	0.4	SOT-227B (minibloc)
DPG10IM300UC	300	10	10	150	20	140	0.98	10	35	5.5	200	175	2.3	TO-252AA
DPG10I300PA	300	10	10	145	35	140	0.98	10	35	5.5	200	175	2.3	TO-220AC
DPG15I300PA	300	15	15	140	35	240	1.01	15	35	6.5	200	175	1.7	TO-220AC
DPG20C300PB	300	20	10	150	35	140	0.98	10	35	5.5	200	175	2.3	TO-220AB
DPG20C300PN	300	20	10	125	35	140	0.98	10	35	5.5	200	175	4.4	TO-220ABFP
DPG30C300PB	300	30	15	145	35	240	1.01	15	35	6.5	200	175	1.7	TO-220AB
DPG30C300HB	300	30	15	145	70	240	1	15	35	6.5	200	175	1.7	TO-247
DPF30I300PA	300	30	30	145	35	390	0.98	30	55	10	200	175	0.85	TO-200AC
DPG30IM300PC	300	30	30	140	-	360	1.08	30	35	7	200	175	0.85	TO-263AB (D2pak)
DPG30I300HA	300	30	30	135	70	360	1.06	30	35	7	200	175	0.95	TO-247AD
DPG30C300PC	300	30	15	145	35	240	1.01	15	35	6.5	200	175	1.7	TO-263AB (D2 PAK)
DPG30I300PA	300	30	30	140	35	340	1.08	30	35	7	200	175	0.85	TO-220AC
DPG30P300PJ	300	30	30	135	35	450	0.98	30	35	8.5	200	175	1.05	ISOPLUS220
DSEP40-03AS	300	40	40	120	35	340	1.2	40	35	7	200	175	0.85	TO-263
DPG60C300PC	300	60	30	140	35	360	1.08	30	35	7	200	175	0.85	TO-263AB
DPG60C300HJ	300	60	30	135	70	450	0.96	30	35	3	200	175	1.05	ISOLPUS-247
DPG60IM300PC	300	60	60	135	35	550	1.14	60	35	9	200	175	0.45	TO-263AB (D2 PAK)
DPG60I300HA	300	60	60	125	70	450	1.1	60	35	9	200	175	0.55	TO-247
DSEP2x31-03A	300	60	30	105	100	300	0.9	30	30	12.5	400	150	1.15	SOT-227B (minibloc)
DPG60C300QB	300	60	30	135	70	360	1.06	30	35	7	200	175	0.95	TO-3P
DPF60C300HB	300	60	30	140	50	400	0.97	30	55	10	200	175	0.95	TO-247AD
DPG60C300HB	300	60	30	135	70	360	1.06	30	35	7	200	175	0.95	TO-247
DPG80C300HB	300	80	40	135	70	450	1.07	40	35	8.5	200	175	0.7	TO-247AD
DSEP2x61-03A	300	120	60	80	100	600	1.11	60	40	15	600	150	0.85	SOT-227B (minibloc)
DPG120C300QB	300	120	60	125	70	450	1.1	60	35	9	200	175	0.55	TO-3P
DSEP2x91-03A	300	180	90	75	100	1000	1.1	90	40	15	600	150	0.6	SOT-227B (minibloc)
DPG10P400PJ	400	10	10	145	35	130	1.02	10	45	5.5	200	175	2.5	ISOPLUS220
DPG10I400PA	400	10	10	145	35	150	1.03	10	45	6	200	175	2.3	TO-220AC
DPG10I400PM	400	10	10	120	35	150	1.03	10	45	6	200	175	4.4	TO-220ACFP
DPG15I400PM	400	15	15	90	35	190	1.14	15	45	5.5	200	175	4.2	TO-220ACFP
DPG20C400PB	400	20	10	145	35	150	1.03	10	45	6	200	175	2.3	TO-220AB
DPG20C400PN	400	20	10	120	35	150	1.03	10	45	6	200	175	4.4	TO-220ABFP
DPG20C400PC	400	20	10	145	35	150	1.03	10	45	6	200	175	2.3	TO-263AB
DPG30C400PB	400	30	15	140	35	190	1.14	15	45	5.5	200	175	1.7	TO-220AB
DPG30IM400PC	400	30	30	145	-	300	1.16	30	45	8.5	200	175	0.85	TO-263AB (D2Pak)
DPG30P400PJ	400	30	30	135	35	400	1.05	30	45	8.5	200	175	1.05	ISOPLUS220
DPG30I400HA	400	30	30	135	70	360	1.13	30	45	8.5	200	175	0.95	TO-247AD
DPG30C400HB	400	30	15	140	70	190	1.13	15	45	5.5	200	175	1.7	TO-247
DPG60C400QB	400	60	30	135	70	360	1.13	30	45	8.5	200	175	0.95	TO-3P
DPG60IM400QB	400	60	60	120	70	450	1.22	60	45	9.5	200	175	0.55	TO-3P
DPG60I400HA	400	60	60	120	70	450	1.22	60	45	9.5	200	175	0.55	TO-247
DSEI2x30-04C	400	60	30	85	70	300	1.4	30	35	10	240	150	1.25	SOT-227B
DSEI2x31-04C	400	60	30	85	70	300	1.4	30	35	10	240	150	1.25	SOT-227B
DPF60IM400HB	400	60	60	130	70	600	1.09	60	60	12	200	175	0.55	TO-247
DPG80C400HB	400	80	40	135	70	400	1.14	40	45	4	200	175	0.7	TO-247AD
DSEI2x60-04C	400	120	60	70	100	550	1.5	60	35	19	480	150	0.7	SOT-227B
DSEI2x61-04C	400	120	60	70	100	550	1.5	60	35	19	480	150	0.7	SOT-227B
DSEP2x101-04A	400	200	100	45	100	1000	1.22	100	30	30	600	150	0.6	SOT-227B (minibloc)
DSEC240-04A	400	240	120	115	200	2000	1	120	30	35	600	150	0.2	SOT-227UI (minibloc)
DPF240X400NA	400	240	120	70	150	1200	1.06	120	30	15	200	150	0.5	SOT-227B (minibloc)
DSEP6-06AS	600	6	6	150	20	40	1.34	6	20	5	200	175	2.8	TO-252AA (D PAK)
DSEP6-06BS	600	6	6	140	20	40	1.77	6	15	3	200	175	2.8	TO-252AA (DPak)
DSEI8-06AS	600	8	8	115	16	100	1.3	8	35	2.5	64	150	2.5	TO-263AB (D2 PAK)
DSEI8-06A	600	8	8	115	16	100	1.3	8	35	2.5	64	150	2.5	TO-220AC
DSEP8-06B	600	10	10	125	35	50	1.85	10	25	2.5	200	175	2.5	TO-220AC
DFE10I600PM	600	10	10	100	16	100	1.38	10	35	4	100	150	4.2	TO-220ACFP
DSEP8-06A	600	10	10	135	35	50	1.42	10	30	6	200	175	2.5	TO-220AC
DSEI12-06A	600	14	14	100	25	100	1.5	16	35	4	100	150	2	TO-220AC
DSEI12-06AS	600	14	14	100	25	100	1.5	16	35	4	100	150	2	TO-263AB (D2 PAK)
DSEP15-06AS	600	15	15	140	35	110	1.35	15	35	7	200	175	1.6	TO-263AB (D2-Pak)
DSEP15-06BS	600	15	15	130	35	110	1.59	15	25	3	200	175	1.6	TO-263AB (D2-Pak)
DSEP15-06B	600	15	15	130	35	110	1.59	15	25	3	200	175	1.6	TO-220AC
DPG30I600PM	600	16	16	95	-	250	1.63	30	25	4.5	200	175	3.5	TO-220ACFP
DSEC16-06AC	600	20	10	135	35	50	1.42	10	30	6	200	175	2.5	ISOPLUS220?
DSEI19-06AS	600	20	20	65	25	100	1.5	16	35	4	100	150	2	TO-263AB (D2 PAK)
DSEC16-06A	600	20	10	135	35	50	1.42	10	30	6	200	175	2.5	TO-220AB
DSEI25-06A	600	25	25	110	35	240	1.55	25	50	14	200	150	1.2	TO-220AC
DSEI25-06AS	600	25	25	110	35	240	1.55	25	50	14	200	150	1.2	TO-263AB (D2Pak)
DFE25I600HA	600	25	25	110	50	240	1.52	25	50	14	200	150	1.2	TO-247AD
DSEP30-06A	600	30	30	135	70	250	1.25	30	35	10	200	175	0.9	TO-247AC
DSEC29-06AC	600	30	15	140	35	110	1.34	15	35	7	200	175	1.6	ISOPLUS220?
DSEC30-06B	600	30	15	130	50	110	1.58	15	25	3	200	175	1.6	TO-247AD
DSEP30-06BR	600	30	30	110	70	250	1.61	30	25	4.5	200	175	1.1	ISOPLUS247?
DSEP30-06B	600	30	30	120	70	250	1.61	30	25	4.5	200	175	0.9	TO-247AC
DSEC30-06A	600	30	15	140	50	110	1.34	15	35	7	200	175	1.6	TO-247AD
DSEP29-06B	600	30	30	125	35	200	1.63	30	25	4.5	200	175	0.9	TO-220AC
DSEP29-06AS	600	30	30	135	35	250	1.26	30	35	10	200	175	0.9	TO-263AB (D2-Pak)
DSEI36-06AS	600	37	37	85	70	300	1.4	37	35	10	240	150	1	TO-263AB (D2 PAK)
DSEI30-06A	600	37	37	85	70	300	1.4	37	35	10	240	150	1	TO-247
DSEP60-06AT	600	60	60	130	70	600	1.39	60	35	13	200	175	0.4	TO-268 (D3Pak)
DPG60B600LB	600	60	30	125	-	250	1.59	30	40	12	400	175	1.1	SMPD
DSEP60-06A	600	60	60	130	70	600	1.39	60	35	13	200	175	0.45	TO-247AC
DSEI60-06A	600	60	60	70	100	550	1.5	70	35	19	480	150	0.75	TO-247
DSEI2x31-06C	600	60	30	85	70	300	1.4	30	35	10	240	150	1.25	SOT-227B
DSEP2x31-06A	600	60	30	100	100	250	1.23	30	30	20	400	150	1.15	SOT-227B (minibloc)
DSEP2x31-06B	600	60	30	75	100	250	1.59	30	20	12.5	400	150	1.15	SOT-227B (minibloc)
DSEC60-06B	600	60	30	120	70	250	1.61	30	25	4.5	200	175	0.9	TO-247AD
DSEI2x30-06C	600	60	30	85	70	300	1.4	30	35	10	240	150	1.25	SOT-227B
DSEC59-06BC	600	60	30	110	60	250	1.61	30	25	4.5	200	175	1.1	ISOPLUS220?
DSEP75-06AR	600	75	75	115	-	1000	2.33	75	35	11	200	175	0.5	ISOPLUS247
DSEP2x61-06A	600	120	60	70	100	600	1.35	60	35	13	200	150	0.85	SOT-227B (minibloc)
DSEI2x61-06P	600	120	60	70	100	550	1.5	60	35	19	480	150	0.7	ECO-PAC 1
DSEI2x61-06C	600	120	60	70	100	550	1.5	60	35	19	480	150	0.7	SOT-227B
DSEI120-06A	600	126	126	70	100	600	1.12	70	120	13	200	150	0.35	TO-247
DSEP2x91-06A	600	180	90	60	100	1000	1.39	90	30	30	600	150	0.6	SOT-227B (minibloc)
DSEI2x101-06A	600	192	96	70	150	1200	1.17	100	80	40	600	150	0.5	SOT-227B
DSEI2x101-06P	600	192	96	70	150	1200	1.17	100	40	19	200	150	0.5	ECO-PAC 2
DFE240X600NA	600	240	120	80	-	1200	1.2	120	80	40	600	150	0.4	SOT-227B (minibloc)
DSEC240-06A	600	240	120	110	200	2000	1.26	120	35	19	400	150	0.2	SOT-227UI (unisolated minibloc)
DSEI2x161-06P	600	294	147	70	270	1200	1.45	200	35	45	200	150	0.29	ECO-PAC 2
DSEK300-06A	600	300	150	110	-	2000	1.02	150	60	50	600	150	0.2	SOT-227UI (minibloc unisolated)
DSEI12-10A	1000	12	12	100	25	75	2.1	12	50	6.5	100	150	1.6	TO-220AC
DSEI30-10A	1000	30	30	85	70	200	2	36	35	16	240	150	0.9	TO-247
DSEI30-10AR	1000	30	30	85	70	200	2	36	35	16	240	150	0.9	ISOPLUS247?
DSEI2x30-10B	1000	60	30	50	70	200	2	30	35	16	240	150	1.25	SOT-227B
DSEI2x31-10B	1000	60	30	50	70	200	2	30	35	16	240	150	1.25	SOT-227B
DSEI2x61-10B	1000	120	60	50	100	500	1.8	60	35	32	480	150	0.7	SOT-227B
DSEP8-12A	1200	10	10	135	35	40	1.96	10	40	8	200	175	2.5	TO-220AC
DSEI12-12AZ	1200	11	11	100	25	75	2.2	12	50	6.5	100	150	1.6	TO-263AB (D2Pak)
DSEI12-12A	1200	11	11	100	25	75	2.2	12	50	6.5	100	150	1.6	TO-220AC
DSEP12-12B	1200	12	12	130	-	90	2.06	15	35	3.7	100	175	1.6	TO-220AC
DSEP12-12AZ	1200	12	12	135	-	90	1.87	15	40	9	200	175	1.6	TO-263AB (D2Pak)
DSEP12-12BZ	1200	12	12	130	-	90	2.06	15	35	3.7	100	175	1.6	TO-263AB (D2Pak)
DSEI20-12A	1200	17	17	85	70	130	1.87	12	40	7	100	150	1.6	TO-220AC
DSEC16-12AS	1200	20	10	135	15	40	1.96	10	40	8	200	175	2.5	TO-263AB (D2-Pak)
DSEC16-12A	1200	20	10	135	15	40	1.96	10	40	8	200	175	2.5	TO-220AB
DSEI30-12A	1200	26	26	85	70	200	2.2	30	40	16	240	150	0.9	TO-247
DSEP30-12A	1200	30	30	120	70	200	1.79	30	60	8.5	200	175	0.9	TO-247AC
DSEP30-12B	1200	30	30	100	-	200	2.3	30	140	18	400	175	0.9	TO-247AD
DSEC30-12A	1200	30	15	120	50	90	1.86	15	50	6	200	175	1.6	TO-247AD
DSEP30-12AR	1200	30	30	105	70	200	1.79	30	60	8.5	200	175	1.1	ISOPLUS247?
DSEP29-12B	1200	30	30	100	-	200	2.31	30	140	18	400	175	0.9	TO-220AC
DSEP29-12A	1200	30	30	120	35	200	1.81	30	40	8.5	200	175	0.9	TO-220AC
DSEK60-12A	1200	52	26	85	50	200	2.2	30	40	16	240	150	1.9	TO-247
DSEI2x30-12B	1200	56	28	50	70	200	2.2	30	40	16	240	150	1.25	SOT-227B
DSEI2x31-12B	1200	56	28	50	70	200	2.2	30	40	16	240	150	1.25	SOT-227B
DSEP2x31-12A	1200	60	30	75	100	200	1.77	30	40	24	400	150	1.15	SOT-227B (minibloc)
DSEP60-12AZ	1200	60	60	115	-	500	1.81	60	80	20	200	175	0.45	TO-268AAHV (D3Pak-HV)
DSEC60-12A	1200	60	30	120	70	200	1.79	30	60	8.5	200	175	0.9	TO-247AD
DSEP60-12AR	1200	60	60	115	70	500	1.81	60	40	13	200	175	0.65	ISOPLUS247?
DSEP60-12A	1200	60	60	115	70	500	1.81	60	40	13	200	175	0.45	TO-247AC
DSEP60-12B	1200	60	60	110	-	500	2.2	60	65	11	200	175	0.45	TO-247AD
DSEP90-12AZ	1200	90	90	105	-	800	1.79	90	80	25	200	175	0.35	TO-268AAHV (D3Pak-HV)
DSEI2x61-12B	1200	104	52	50	100	450	2.15	60	40	32	480	150	0.7	SOT-227B
DSEI2x61-12P	1200	104	52	50	100	450	2.15	60	40	32	540	150	0.7	ECO-PAC 1
DSEI120-12A	1200	109	109	60	100	600	1.55	70	190	17	200	150	0.35	TO-247
DSEI120-12AZ	1200	109	109	60	100	600	1.55	70	40	25	200	150	0.35	TO-268AAHV (D3Pak-HV)
DSEC120-12AK	1200	120	60	115	70	500	1.81	60	40	13	200	175	0.45	TO-264
DSEP2x60-12A	1200	120	60	80	100	800	1.52	60	85	20	200	150	0.6	SOT-227B (minibloc)
DSEP2x61-12B	1200	120	60	80	-	800	2	60	70	17	200	150	0.6	SOT-227B (minibloc)
DSEP2x61-12A	1200	120	60	80	100	800	1.52	60	85	20	200	150	0.6	SOT-227B (minibloc)
DSEI2x101-12A	1200	182	91	50	130	1200	1.61	100	150	52	600	150	0.5	SOT-227B
DSEI2x101-12P	1200	182	92	50	130	900	1.61	100	40	24	200	150	0.5	ECO-PAC 2
DSEI2x161-12P	1200	256	128	70	270	1200	1.9	200	40	48	200	150	0.29	ECO-PAC 2

PartNumber	VRRM	IFAVM	IFAVM	@TC	VF	@IF	TVJM	RthJC	Package
	(V)	d=0.5	d=0.5	(°C)	max	(A)	(°C)	max	Style
		Total	PerDiode		TVJ=125°C			(K/W)
		(A)	(A)		(V)
DSS20-0015B	15	20	20	135	0.33	20	150	1.4	TO-220AC
DSA50C100QB	100	50	25	155	0.72	25	175	0.95	TO-3P
DSA20C150PB	150	20	10	155	0.73	10	175	2.4	TO-220AB
DSA30C150PB	150	30	15	155	0.75	15	175	1.75	TO-220AB
DSA70C150HB	150	70	35	150	0.77	35	175	0.7	TO-247
DSA120C150QB	150	120	60	150	0.8	60	175	0.4	TO-3P
DSSK60-02A	200	60	30	155	0.7	30	175	0.8	TO-247
DSA90C200HB	200	90	45	145	0.86	45	175	0.55	TO-247
DSS40-0008D	8	40	40	135	0.23	40	150	0.8	TO-247
DSSK80-0008D	8	80	40	135	0.23	40	150	0.8	TO-247
DSS2x200-0008D	8	400	200	100	0.15	100	150	0.4	SOT-227UI
DSB20I15PA	15	20	20	130	0.39	20	150	1.75	TO-220AC
DSSK40-0015B	15	40	20	135	0.32	20	150	1.4	TO-247
DSB40C15PB	15	40	20	130	0.39	20	150	1.75	TO-220AB
DSSK70-0015B	15	70	35	130	0.33	35	150	1.1	TO-247
DSS6-0025BS	25	6	6	140	0.3	6	150	3	TO-252AA (D PAK)
DSSK18-0025BS	25	20	10	140	0.37	10	150	1.7	TO-263AB (D2 PAK)
DSS25-0025B	25	25	25	125	0.44	25	150	1.4	TO-220AC
DSSK38-0025BS	25	40	20	130	0.4	20	150	1.4	TO-263AB (D2 PAK)
DSSK38-0025B	25	40	20	130	0.4	20	150	1.4	TO-220AB
DSSK50-0025B	25	50	25	125	0.42	25	150	1.4	TO-247
DSSK48-0025B	25	50	25	130	0.35	20	150	1.2	TO-220AB
DSSK80-0025B	25	80	40	130	0.39	40	150	0.8	TO-247
DSB15IM30UC	30	15	15	130	0.44	15	150	2	TO-252AA (DPak)
DSB30C30PB	30	30	15	135	0.44	15	150	1.75	TO-220AB
DSSK48-003BS	30	50	25	130	0.35	20	150	1.2	TO-263AB (D2 PAK)
DSSK48-003B	30	50	25	130	0.35	20	150	1.2	TO-220AB
DSB60C30PB	30	60	30	130	0.49	30	150	0.85	TO-220AB
DSB60C30HB	30	60	30	130	0.47	30	150	0.95	TO-247
DSSK70-003B	30	70	35	125	0.39	35	150	1.1	TO-247
DSSK80-003B	30	80	40	130	0.39	40	150	0.8	TO-247
DSS6-0045AS	45	6	6	165	0.5	6	175	3	TO-252AA (D PAK)
DSS10-0045B	45	10	10	135	0.46	10	150	1.7	TO-220AC
DSB10I45PM	45	10	10	115	0.52	10	150	4.5	TO-220ACFP
DSA15IM45UC	45	15	15	150	0.63	15	175	2	TO-252AA (DPak)
DSA15I45PA	45	15	15	155	0.63	15	175	1.75	TO-220AC
DSA15IM45IB	45	15	15	155	0.63	15	175	1.75	TO-262 (i2-Pac)
DSA30C45PC	45	15	30	155	0.63	15	175	1.75	TO-263AB (D2Pak)
DSB15IM45IB	45	15	15	130	0.55	15	150	1.75	TO-262 (i2-Pac)
DSS16-0045AS	45	16	16	160	0.57	15	175	1.4	TO-263AB (D2 PAK)
DSS16-0045A	45	16	16	160	0.57	15	175	1.4	TO-220AC
DSA20C45PB	45	20	10	160	0.61	10	175	2.4	TO-220AB
DSSK20-0045B	45	20	10	135	0.45	10	150	1.7	TO-220AB
DSS25-0045A	45	25	25	155	0.59	25	175	1.1	TO-220AC
DSB30C45PB	45	30	15	130	0.55	15	150	1.75	TO-220AB
DSB30C45HB	45	30	15	130	0.54	15	150	1.75	TO-247
DSA30C45PB	45	30	15	155	0.63	15	175	1.75	TO-220AB
DSA30C45HB	45	30	15	155	0.62	15	175	1.75	TO-247
DSSK28-0045BS	45	30	15	135	0.43	15	150	1.4	TO-263AB (D2 PAK)
DSB60C45HB	45	60	30	125	0.58	30	150	0.95	TO-247
DSSK60-0045A	45	60	30	150	0.6	30	175	1.1	TO-247
DSSK60-0045B	45	60	30	120	0.44	30	150	1.1	TO-247
DSB60C45PB	45	60	30	125	0.6	30	150	0.85	TO-220AB
DSS60-0045B	45	60	60	100	0.57	60	150	0.8	TO-247
DSA60C45PB	45	60	30	155	0.67	30	175	0.85	TO-220AB
DSA60C45HB	45	60	30	155	0.66	30	175	0.95	TO-247
DSA80C45HB	45	80	40	150	0.67	40	175	0.7	TO-247
DSB80C45HB	45	80	40	125	0.59	40	150	0.7	TO-247
DSSK80-0045B	45	80	40	125	0.45	40	150	0.8	TO-247
DSS2x61-0045A	45	120	60	110	0.65	60	150	0.8	SOT-227B
DSS2x81-0045B	45	160	80	85	0.63	80	150	0.8	SOT-227B
DSS2x121-0045B	45	240	120	100	0.59	120	150	0.4	SOT-227B
DSA300I45NA	45	300	300	100	0.76	300	150	0.15	SOT-227B (minibloc)
DSS2x160-0045A	45	320	160	100	0.73	160	150	0.3	SOT-227B
FUS45-0045B	45	-	-	-	-	-	-	3.1	ISOPLUS i4-PAC? (5 - Lead)
DSS2-60AT2	60	2	2	85	0.43	2	175	-	TO-92
DSB10P60PN	60	10	10	110	0.62	10	150	4.5	TO-220ABFP
DSS10-006A	60	10	10	160	0.62	10	175	1.6	TO-220AC
DSA20C60PN	60	20	10	140	0.7	10	175	4.5	TO-220ABFP
DSB20C60PN	60	20	10	110	0.62	10	150	4.5	TO-220ABFP
DSB30C60PB	60	30	15	130	0.64	15	150	1.75	TO-220AB
DSSK28-006BS	60	30	15	135	0.52	15	150	1.1	TO-263AB (D2 PAK)
DSA30C60PB	60	30	15	155	0.72	15	175	1.75	TO-220AB
DSSK40-006B	60	40	20	130	0.46	20	150	1.1	TO-247
DSA60C60HB	60	60	30	150	0.75	30	175	0.95	TO-247
DSB60C60PB	60	60	30	125	0.69	30	150	0.85	TO-220AB
DSA60C60PB	60	60	30	150	0.77	30	175	0.85	TO-220AB
DSB60C60HB	60	60	30	125	0.67	30	150	0.95	TO-247
DSSK80-006B	60	80	40	120	0.51	40	150	0.8	TO-247
DSSK80-006BR	60	80	40	120	0.51	40	150	0.8	ISOPLUS247?
DSSS35-008AR	80	35	35	150	0.68	35	175	0.8	ISOPLUS247?
DSSK40-008B	80	40	20	130	0.57	20	150	1.1	TO-247
DSSK70-008A	80	70	35	150	0.66	35	175	0.8	TO-247
DSSK70-008AR	80	70	35	150	0.64	35	175	0.8	ISOPLUS247?
DSS2x111-008A	80	220	110	105	0.72	100	150	0.4	SOT-227B
DSS10-01AS	100	10	10	160	0.65	10	175	1.7	TO-263AB (D2 PAK)
DSA10I100PM	100	10	10	140	0.71	10	175	4.5	TO-220ACFP
DSA10IM100UC	100	10	10	150	0.71	10	175	3	TO-252AA (DPak)
DSS10-01A	100	10	10	160	0.65	10	175	1.7	TO-220AC
DSS16-01AS	100	16	16	155	0.64	15	175	1.4	TO-263AB (D2 PAK)
DSS16-01A	100	16	16	155	0.64	15	175	1.4	TO-220AC
DSSK16-01A	100	16	8	165	0.65	10	175	1.7	TO-220AB
DSSK16-01AS	100	16	8	165	0.65	10	175	1.7	TO-263AB (D2 PAK)
DSS20-01AC	100	20	20	140	0.65	10	175	1.7	ISOPLUS220?
DSA20C100PN	100	20	10	140	0.71	10	175	4.5	TO-220ABFP
DSA20C100PB	100	20	10	155	0.71	10	175	2.4	TO-220AB
DSA30C100HB	100	30	15	150	0.72	15	175	1.75	TO-247AD
DSA30C100PN	100	30	15	120	0.73	15	175	4.2	TO-220ABFP
DSA30C100PB	100	30	15	155	0.73	15	175	1.75	TO-220AB
DSA30C100QB	100	30	15	150	0.72	15	175	1.75	TO-3P
DSSK30-01A	100	30	15	160	0.64	15	175	1.4	TO-247
DSSS30-01AR	100	30	30	155	0.63	30	175	0.8	ISOPLUS247?
DSSK28-01AS	100	30	15	160	0.63	15	175	1.4	TO-263AB (D2 PAK)
DSA30I100PA	100	30	30	150	0.78	30	175	0.85	TO-220AC
DSA50C100HB	100	50	25	155	0.72	25	175	0.95	TO-247
DSSK50-01A	100	50	25	155	0.65	25	175	1.1	TO-247
DSA60C100PB	100	60	30	150	0.78	30	175	0.85	TO-220AB
DSA70C100HB	100	70	35	150	0.74	35	175	0.7	TO-247
DSA80C100PB	100	80	40	150	0.8	40	175	0.6	TO-220AB
DSS2x41-01A	100	80	40	110	0.7	40	150	1.1	SOT-227B
DSS2x61-01A	100	120	60	105	0.74	60	150	0.8	SOT-227B
DSA300I100NA	100	300	300	95	0.88	300	150	0.15	SOT-227B (minibloc)
DSS2x160-01A	100	320	160	95	0.8	160	150	0.3	SOT-227UI
DSS6-015AS	150	6	6	160	0.62	6	175	3	TO-252AA (D PAK)
DSA10C150PB	150	10	5	160	0.71	5	175	4.8	TO-220AB
DSA10C150UC	150	10	5	155	0.71	5	175	4.8	TO-252AA (DPak)
DSA15IM150UC	150	15	15	150	0.75	15	175	2	TO-252AA (DPak)
DSA20C150PN	150	20	10	140	0.73	10	175	4.5	TO-220ABFP
DSSK20-015A	150	20	10	165	0.65	10	175	1.4	TO-220AB
DSA30C150HB	150	30	15	150	0.74	15	175	1.75	TO-247
DSA30I150PA	150	30	30	150	0.8	30	175	0.85	TO-220AC
DSA50C150HB	150	50	25	155	0.74	25	175	0.95	TO-247
DSSK50-015A	150	50	25	150	0.68	25	175	1.1	TO-247
DSA60C150PB	150	60	30	150	0.8	30	175	0.85	TO-220AB
DSSK60-015A	150	60	30	155	0.69	30	175	0.8	TO-247
DSSK60-015AR	150	60	30	155	0.69	30	175	0.8	ISOPLUS247?
DSA120X150LB	150	150	75	135	0.74	60	175	0.8	SMPD
DSS2x101-015A	150	200	100	110	0.77	100	150	0.4	SOT-227B
DSA240X150NA	150	240	120	95	0.85	120	150	0.4	SOT-227B (minibloc)
DSSK10-018A	180	10	5	165	0.62	5	175	1.7	TO-220AB
DSSK30-018A	180	30	15	150	0.72	15	175	1.7	TO-247
DSA15IM200UC	200	15	15	150	0.78	15	175	2	TO-252AA (DPak)
DSA30C200PB	200	15	15	155	0.78	15	175	1.75	TO-220AB
DSA20C200PB	200	20	10	155	0.75	10	175	2.4	TO-220AB
DSA30C200IB	200	30	15	155	0.78	15	175	1.75	TO-262 (I2-Pak)
DSSK60-02AR	200	60	30	155	0.7	30	175	0.8	ISOPLUS247?
DSA70C200HB	200	70	35	150	0.79	35	175	0.7	TO-247AD
DSA90C200HR	200	90	45	145	0.79	45	175	0.7	ISO-247
DSA120X200LB	200	130	65	130	0.82	60	175	0.8	SMPD
DSS2x101-02A	200	200	100	105	0.84	100	150	0.4	SOT-227B
DSA240X200NA	200	240	120	95	0.87	120	150	0.4	SOT-227B (minibloc)

PartNumber	VRRM	IFAVM	IFAVM	@Tc	PRSM	IFSM	VT0	rT	Tvjm	RthJC	RthCH
	(V)	Total	perDiode	(°C)	(kW)	10ms	(V)	(mOhms)	(°C)	max	(K/W)
		(A)	(A)			Tvj=45°C				(K/W)
						(A)
DSI45-08A	800	45	45	130	-	480	0.81	9.1	175	0.55	0.25
DSP8-12A	1200	8	8	160	-	120	0.79	33	175	1.5	0.5
DSI45-12A	1200	45	45	130	-	480	0.81	9.1	175	0.55	0.25
DSI2x55-12A	1200	120	60	95	-	800	0.83	6.2	150	0.6	0.1
DSI45-16A	1600	45	45	130	-	480	0.81	9.1	175	0.55	0.25
DLA5P800UC	800	5	5	155	-	70	0.82	58	175	2.5	0.5
DSP8-08S	800	8	8	160	-	120	0.79	33	175	1.5	0.25
DSP8-08AS	800	8	8	160	-	120	0.79	33	175	1.5	0.25
DSP8-08A	800	8	8	160	-	120	0.79	33	175	1.5	0.5
DLA10IM800UC	800	10	10	145	-	120	0.84	30	175	2.5	0.5
DLA20IM800PC	800	20	20	140	-	200	0.86	19	175	1	0.25
DSI30-08AC	800	30	30	95	-	200	0.8	15	150	1.1	0.6
DSI30-08A	800	30	30	130	-	300	0.82	14.1	175	0.9	0.5
DSI30-08AS	800	30	30	130	-	300	0.82	14.1	175	0.9	0.25
DLA40IM800PC	800	40	40	120	-	300	0.85	10	175	0.8	0.25
DSI35-08A	800	49	49	100	-	650	0.85	4.5	180	1.05	0.2
DSA1-12D	1200	2.3	2.3	100	1.6	110	0.8	67	150	-	-
DS2-12A	1200	3.6	3.6	100	-	120	0.85	43	180	-	-
DSP8-12S	1200	8	8	160	-	120	0.79	33	175	1.5	0.25
DSP8-12AS	1200	8	8	160	-	120	0.79	33	175	1.5	0.25
DMA10P1200HR	1200	10	10	145	-	120	0.81	34	175	2	0.25
DSA9-12F	1200	11	11	100	4.5	250	0.85	15	180	2	1
DSP8-12AC	1200	11	11	100	-	100	0.8	41	150	1.8	0.6
DSP25-12AT	1200	25	25	135	-	300	0.81	13.8	175	0.9	0.15
DSP25-12A	1200	25	25	135	-	300	0.81	13.8	175	0.9	0.25
DSA17-12A	1200	25	25	125	7	370	0.85	8	180	1.5	0.6
DSI17-12A	1200	25	25	125	-	370	0.85	8	180	1.5	0.6
DSAI17-12A	1200	25	25	125	7	370	0.85	8	180	1.5	0.6
DS17-12A	1200	25	25	125	-	370	0.85	8	180	1.5	0.6
DMA30P1200HB	1200	30	30	130	-	370	0.81	12.7	175	0.8	0.25
DSI30-12AS	1200	30	30	130	-	300	0.82	14.1	175	0.9	0.25
DSI30-12AC	1200	30	30	95	-	200	0.8	15	150	1.1	0.6
DSI30-12A	1200	30	30	130	-	300	0.82	14.1	175	0.9	0.5
DSP45-12A	1200	45	45	130	-	480	0.81	9.1	175	0.55	0.25
DSP45-12AZ	1200	45	45	130	-	480	0.81	9.1	175	0.55	0.15
DSI35-12A	1200	49	49	100	-	650	0.85	4.5	180	1.05	0.2
DS35-12A	1200	49	49	100	-	650	0.85	4.5	180	1.05	0.2
DSAI35-12A	1200	49	49	100	11	650	0.85	4.5	180	1.05	1.25
DSA35-12A	1200	49	49	100	11	650	0.85	4.5	180	1.05	1.25
DMA50P1200HR	1200	50	50	105	-	650	0.82	9	175	0.7	0.25
DMA50P1200HB	1200	50	50	130	-	650	0.81	8.6	175	0.45	0.25
DLA60I1200HA	1200	60	60	150	-	850	0.78	5.1	175	0.3	0.25
DSI75-12B	1200	110	110	100	-	1400	0.75	2	180	0.5	0.3
DS75-12B	1200	110	110	100	-	1400	0.75	2	180	0.5	0.3
DSAI75-12B	1200	110	110	100	20	1400	0.75	2	180	0.5	0.3
DSA75-12B	1200	110	110	100	20	1400	0.75	2	180	0.5	0.3
DSA2-12A	1600	2	2	100	2.5	120	0.85	43	180	-	-
DSA1-16D	1600	2.3	2.3	100	1.6	110	0.8	67	150	-	-
DSA2-16A	1600	3.6	3.6	100	2.5	120	0.85	43	180	-	-
DMA10I1600PA	1600	10	10	150	-	120	0.82	37	175	1.5	0.5
DMA10P1600HR	1600	10	10	145	-	120	0.81	34	175	2	0.25
DMA10P1600PZ	1600	10	10	150	-	120	0.82	37	175	1.5	0.25
DMA10IM1600PZ	1600	10	10	150	-	120	0.82	37	175	1.5	1.75
DSA9-16F	1600	11	11	100	4.5	250	0.85	15	180	2	1
DSAI17-16A	1600	25	25	125	7	370	0.85	8	180	1.5	0.6
DSA17-16A	1600	25	25	125	7	370	0.85	8	180	1.5	0.6
DSP25-16A	1600	25	25	135	-	300	0.81	13.8	175	0.9	0.25
DSP25-16AT	1600	25	25	135	-	300	0.81	13.8	175	0.9	0.15
DSP25-16AR	1600	25	25	110	-	300	0.81	13.8	175	1.5	0.25
DSI30-16AS	1600	30	30	130	-	300	0.82	14.1	175	0.9	0.25
DSI30-16A	1600	30	30	130	-	300	0.82	14.1	175	0.9	0.5
DMA30P1600HB	1600	30	30	130	-	370	0.81	12.7	175	0.8	0.25
DMA30IM1600PZ	1600	30	30	140	-	300	0.82	14.1	175	0.7	0.25
DMA30P1600HR	1600	30	30	105	-	300	0.82	13.5	175	1.3	0.25
DSP45-16AZ	1600	45	45	130	-	480	0.81	9.1	175	0.55	0.15
DSP45-16AR	1600	45	45	100	-	480	0.81	9.1	175	0.9	0.25
DSP45-16A	1600	45	45	130	-	480	0.81	9.1	175	0.55	0.25
DSI45-16AR	1600	45	45	100	-	480	0.81	9.1	175	0.9	0.25
DSAI35-16A	1600	49	49	100	11	650	0.85	4.5	180	1.05	1.25
DSA35-16A	1600	49	49	100	11	650	0.85	4.5	180	1.05	1.25
DMA50P1600HB	1600	50	50	130	-	650	0.81	12.7	175	0.45	0.25
DSIK45-16AR	1600	90	45	100	-	480	0.81	9.1	175	0.9	0.25
DSA75-16B	1600	110	110	100	20	1400	0.75	2	180	0.5	0.3
DSAI75-16B	1600	110	110	100	20	1400	0.75	2	180	0.5	0.3
DSI2x55-16A	1600	120	60	95	-	800	0.83	6.2	150	0.6	0.1
DMA150E1600NA	1600	150	150	110	-	3000	0.78	1.8	150	0.2	0.1
DMA200X1600NA	1600	200	100	100	-	1500	0.8	4	150	0.3	0.1
DMA200XA1600NA	1600	200	100	100	-	1500	0.8	4	150	0.3	0.1
DSA1-18D	1800	2.3	2.3	100	1.6	110	0.8	67	150	-	-
DSA2-18A	1800	3.6	3.6	100	2.5	120	0.85	43	180	-	-
DAA10P1800PZ	1800	10	10	150	1.6	150	0.82	37	175	1.5	0.25
DAA10EM1800PZ	1800	10	10	1500	1.6	150	0.81	32	175	1.5	0.25
DMA10P1800PZ	1800	10	10	150	-	120	0.82	37	175	1.5	0.25
DSA9-18F	1800	11	11	100	4.5	250	0.85	15	180	2	1
DSA17-18A	1800	25	25	125	7	370	0.85	8	180	1.5	0.6
DSAI17-18A	1800	25	25	125	7	370	0.85	8	180	1.5	0.6
DMA30E1800HA	1800	30	30	140	-	370	0.83	12.8	175	0.7	0.25
DSP45-18A	1800	45	45	130	-	480	0.81	9.1	175	0.55	0.25
DSAI35-18A	1800	49	49	100	11	650	0.85	4.5	180	1.05	1.25
DSA35-18A	1800	49	49	100	11	650	0.85	4.5	180	1.05	1.25
DSAI75-18B	1800	110	110	100	20	1400	0.75	2	180	0.5	0.3
DSA75-18B	1800	110	110	100	20	1400	0.75	2	180	0.5	0.3
DAA200X1800NA	1800	200	100	100	20	1500	0.8	4	150	0.3	0.1
DAA200XA1800NA	1800	200	100	100	20	1500	0.8	4	150	0.3	0.1
DNA30EM2200PZ	2200	30	30	140	-	370	0.83	13.4	175	0.7	0.25
DNA30ER2200IY	2200	30	30	140	-	370	0.83	13.4	175	0.7	0.5
DNA30E2200FE	2200	30	30	110	-	370	0.83	12.8	175	1.35	0.2
DNA30E2200PA	2200	30	30	140	-	370	0.83	13.4	175	0.7	0.5
DNA30E2200PZ	2200	30	30	140	-	370	0.83	13.4	175	0.7	0.25

PartNumber	VRRM	ITAVM	@TC	ITRMS	ITSM	ITSM	[dv/dt]C	VT0	rT	TVJM	RthJC	RthCH	Package
	VDRM	(A)	(°C)	(A)	10ms	8.33ms	(V/μs)	(V)	(mOhm)	(°C)	max	(K/W)	Style
	(V)				TVJ=45°C	TVJ=45°C					(K/W)
					(A)	(A)
CS19-08ho1	800	20	110	31	180	195	500	0.86	22	150	0.7	0.5	TO-220AB
CLA50E1200HB	1200	50	125	79	650	700	1000	0.88	7.7	150	0.25	0.25	TO-247AD
CS60-12io1	1200	60	110	75	1400	1510	1000	0.82	5.3	140	0.32	0.15	PLUS247
CLA80E1200HF	1200	80	115	126	900	970	1000	0.88	6.3	150	0.2	0.25	PLUS247
CS30-16io1	1600	30	120	47	400	430	1000	0.87	14.2	150	0.5	0.25	TO-247
CS45-16io1	1600	45	110	71	520	560	1000	0.88	11	150	0.4	0.25	TO-247
CS60-16io1	1600	60	110	75	1400	1510	1000	0.82	5.3	140	0.32	0.15	PLUS247
CS22-08io1M	800	16	85	25	300	325	500	0.86	13.2	150	2.5	0.5	TO-220ABFP
CS19-08ho1S	800	20	110	31	180	195	500	0.86	22	150	0.7	0.25	TO-263 (D2 PAK)
CS23-08io2	800	25	85	50	450	480	1000	1	10	125	1	0.6	TO-208AA (TO-48)
CS45-08io1	800	45	110	71	520	560	1000	0.88	11	150	0.4	0.25	TO-247
CS35-08io4	800	63	85	120	1200	1340	1000	0.85	3.5	125	0.4	0.2	TO-208AC (TO-65)
CLA5E1200PZ	1200	5	135	7.8	70	76	500	0.89	85	150	1.5	0.25	TO-263ABHV (D2Pak-HV)
CLA5E1200UC	1200	5	135	7.8	70	76	500	0.89	85	150	1.5	0.5	TO-252AA
CLA16E1200PN	1200	10	90	16	180	195	500	0.81	24	150	4	0.5	TO-220ABFP
CLA16E800PN	1200	10	90	16	180	195	500	0.81	24	150	4	0.5	TO-220ABFP
CLA15E1200NPB	1200	15	120	33	170	185	500	0.89	30	150	0.95	0.5	TO-220AB
CLA15E1200NPZ	1200	15	120	33	170	185	500	0.89	30	150	0.95	0.25	TO-263ABHV (D2Pak-HV)
CS22-12io1M	1200	16	85	25	300	325	500	0.86	13.2	150	2.5	0.5	TO-220ABFP
CLA20EF1200PZ	1200	20	115	-	120	130	500	0.9	25	150	0.65	0.25	TO-263ABHV (D2Pak-HV)
CLA20EF1200PB	1200	20	115	-	120	130	500	0.9	25	150	0.65	0.5	TO-220AB
CS19-12ho1	1200	20	110	31	180	195	500	0.86	22	150	0.7	0.5	TO-220AB
CS19-12ho1S	1200	20	110	31	180	195	500	0.86	22	150	0.7	0.25	TO-263 (D2 PAK)
CS20-12io1	1200	20	130	31	260	280	1000	0.87	17.3	150	0.6	0.25	TO-247
CLF20E1200PB	1200	20	85	31	160	175	500	1.07	42	150	1	0.5	TO-220AB
CLE20E1200PC	1200	20	95	-	160	175	500	0.87	34	150	1	0.25	TO-263AB
CS23-12io2	1200	25	85	50	450	480	1000	1	10	125	1	0.6	TO-208AA (TO-48)
CLA30E1200NPZ	1200	30	115	47	300	325	500	0.86	13.2	150	0.5	0.25	TO-263ABHV (D2Pak-HV)
CLA30E1200HB	1200	30	120	47	300	325	500	0.86	12.5	150	0.5	0.25	TO-247AD
CS30-12io1	1200	30	120	47	400	430	1000	0.87	14.2	150	0.5	0.25	TO-247
CLA30E1200PB	1200	30	115	47	300	325	500	0.86	13.2	150	0.5	0.5	TO-220AB
CLA30E1200PC	1200	30	115	47	300	325	500	0.86	13.2	150	0.5	0.25	TO-263AB
CLB30I1200HB	1200	30	120	47	300	325	500	0.86	12.5	150	0.5	0.25	TO-247AD
CLB30I1200PZ	1200	30	115	47	300	325	500	0.86	13.2	150	0.5	0.25	TO-263ABHV (D2Pak-HV)
CLE30E1200PB	1200	30	85	-	350	380	500	0.92	14	150	0.5	0.5	TO-220AB
CLA40E1200HR	1200	40	95	63	650	700	1000	0.86	7.9	150	0.8	0.25	ISO247
CLA40P1200FC	1200	40	95	63	650	700	1000	0.86	7.9	150	0.8	0.2	i4-pac
CLA40E1200NPZ	1200	40	125	63	520	560	500	0.85	9.9	150	0.4	0.25	TO-263ABHV (D2Pak-HV)
CLE40E1200HB	1200	40	130	63	600	650	1000	0.97	9	150	0.25	0.25	TO-247AD
CLB40I1200PZ	1200	40	125	63	520	560	500	0.85	9.9	150	0.4	0.25	TO-263ABHV (D2Pak-HV)
CS45-12io1	1200	45	110	71	520	560	1000	0.88	11	150	0.4	0.25	TO-247
CLA50E1200TC	1200	50	125	79	650	700	1000	0.88	7.7	150	0.25	0.15	TO-268 (D3-Pak)
CS35-12io4	1200	63	85	120	1200	1340	1000	0.85	3.5	125	0.4	0.2	TO-208AC (TO-65)
CLE90UH1200TLB	1200	90	90	-	350	380	500	0.92	0.13	150	0.9	0.4	SMPD
CLA100E1200KB	1200	100	105	160	1100	1190	1000	0.82	5.2	150	0.2	0.15	TO-264
CLA100E1200HB	1200	100	105	160	1100	1190	1000	0.82	5.2	150	0.2	0.15	TO-247AD
CS20-14io1	1400	20	130	31	260	280	1000	0.87	17.3	150	0.6	0.25	TO-247
CS30-14io1	1400	30	120	47	400	430	1000	0.87	14.2	150	0.5	0.25	TO-247
CS60-14io1	1400	60	110	75	1400	1510	1000	0.82	5.3	140	0.32	0.15	PLUS247
CS35-14io4	1400	63	85	120	1200	1340	1000	0.85	3.5	125	0.4	0.2	TO-208AC (TO-65)
CMA20E1600PZ	1600	20	115	31	180	195	500	0.92	28	150	0.7	0.25	TO-263ABHV (D2Pak-HV)
CMA20E1600PB	1600	20	115	31	180	195	500	0.92	28	150	0.7	0.5	TO-220AB
CS20-16io1	1600	20	130	31	260	280	1000	0.87	17.3	150	0.6	0.25	TO-247
CMA30E1600PN	1600	23	40	36	260	280	500	0.9	17	150	2.5	0.5	TO-220ABFP
CS23-16io2	1600	25	85	50	450	480	1000	1	10	125	1	0.6	TO-208AA (TO-48)
CMA30P1600FC	1600	30	90	47	400	430	1000	0.87	14.2	150	1	0.2	i4-pac
CMA30E1600PZ	1600	30	115	47	260	280	500	0.9	17	150	0.5	0.25	TO-263ABHV (D2Pak-HV)
CME30E1600PZ	1600	30	80	-	260	280	500	1.23	25	150	0.75	0.25	TO-263ABHV (D2Pak-HV)
CMA30E1600PB	1600	30	115	47	260	280	500	0.9	17	150	0.5	0.5	TO-220AB
CMA40E1600HR	1600	40	90	63	550	595	1000	0.81	9.8	150	0.8	0.25	ISO247
CS45-16io1R	1600	45	90	71	520	560	1000	0.88	11	150	0.6	0.25	ISOPLUS247?
CMA50E1600TZ	1600	50	110	79	550	595	1000	0.83	9.6	150	0.4	0.15	TO-268AAHV (D3Pak-HV)
CMA50P1600FC	1600	50	90	79	720	780	1000	0.88	6.7	150	0.7	0.2	i4-Pac
CMA50E1600QB	1600	50	110	79	550	595	1000	0.83	9.6	150	0.4	0.25	TO-3P
CMA50E1600HB	1600	50	110	79	550	595	1000	0.83	9.6	150	0.4	0.25	TO-247 AD
CMA80E1600HB	1600	80	115	126	720	780	1000	0.9	6.4	150	0.2	0.25	TO-247AD
N1075LN180	1800	1240	-	-	-	-	-	-	-	-	-	-
CS20-22moF1	2200	18	85	-	200	215	2500	-	-	125	0.92	0.15	ISOPLUS i4-PAC?
CNA30E2200FB	2200	30	80	47	200	230	5000	-	-	70	-	0.15	i4-Pac
CS20-25mo1F	2500	18	90	-	200	215	2500	-	-	125	0.92	0.15	ISOPLUS i4-PAC?
CS20-25moT1	2500	20	70	-	200	215	5000	-	-	70	0.8	0.15	TO-268AA (D3Pak)

PartNumber	VCES	IC25	IC90	IC100	IC110	VCE(sat)	tfi	Eoff	RthJC	IF	RthJC	Package
	(V)	TC=25°C	TC=90°C	TC=100°C	TC=110°C	max	typ	typ	max	TJ=110°C	max	Style
		IGBT	IGBT	IGBT	IGBT	TJ=25°C	TJ=25°C	TJ=125°C	IGBT	Diode	Diode
		(A)	(A)	(A)	(A)	IGBT	IGBT	IGBT	(oC/W)	(A)	(oC/W)
						(V)	(ns)	(mJ)
IXGH60N60C3D1	600	75	-	-	60	2.5	50	0.8	0.33	26	0.9	TO-247
IXGH48N60C3D1	600	75	-	-	48	2.5	38	0.57	0.42	30	0.9	TO-247
IXGH48N60A3D1	600	-	-	-	48	1.35	224	5.6	0.42	-	0.9	TO-247
IXGH40N30	300	60	40		-	1.8	220	3.3	0.62	-	-	TO-247
IXGH100N30B3	300	75	-		100	1.7	-	-	0.27	-	-	TO-247
IXGH120N30B3	300	75	-		120	1.7	-	-	0.23	-	-	TO-247
IXGH120N30C3	300	75	-	-	120	2.1	86	0.73	0.23	-	-	TO-247
IXGA42N30C3	300	250	-	-	42	1.8	65	0.2	0.56	-	-	TO-263
IXGH42N30C3	300	250	-	-	42	1.8	65	0.2	0.56	-	-	TO-247
IXGP42N30C3	300	250	-	-	42	1.8	65	0.2	0.56	-	-	TO-220
IXGX400N30A	300	400	-		200	1.15	-	-	0.125	-	-	PLUS247
IXGN400N30A3	300	400	-		200	1.15	-	-	0.17	-	-	SOT-227B
IXGX400N30A3	300	400	-		200	1.15	-	-	0.125	-	-	PLUS247
IXGK400N30A3	300	400	-		200	1.15	-	-	0.125	-	-	TO-264
IXGH85N30C3	300	420	-		85	1.9	70	0.39	0.375	-	-	TO-247
IXGH60N30C3	300	420	-		60	1.8	68	0.3	0.42	-	-	TO-247
IXGH100N30C3	300	500	-		100	1.85	94	0.52	0.27	-	-	TO-247
IXGR39N60BD1	600	14	35		-	1.8	200	6	0.9	30	1.1	ISOPLUS247?
IXGP7N60C	600	14	7		-	2.7	45	0.22	2.3	-	-	TO-220
IXGR32N60CD1	600	14	26	-	-	2.7	55	0.85	0.9	26	1.15	ISOPLUS247?
IXGA7N60B	600	14	7	-	-	2	150	0.6	2.3	-	-	TO-263 (D2 PAK)
IXGA7N60BD1	600	14	7	-	-	2	150	0.6	2.3	7	1.6	TO-263 (D2 PAK)
IXGP7N60B	600	14	7		-	2	150	0.6	2.3	-	-	TO-220
IXGA7N60CD1	600	14	7	-	-	2.7	45	0.22	2.3	7	1.6	TO-263 (D2 PAK)
IXGP7N60BD1	600	14	7		-	2	150	0.6	2.3	7	1.6	TO-220
IXGP7N60CD1	600	14	7	-	-	2.7	45	0.22	2.3	7	1.6	TO-220
IXGA7N60C	600	14	7	-	-	2.7	45	0.22	2.3	-	-	TO-263 (D2 PAK)
IXGR12N60C	600	15	8		-	2.7	55	0.27	2.27	-	-	ISOPLUS247?
IXGP20N60B	600	24	12	-	-	2	120	0.8	1.25	-	-	TO-220
IXGA12N60C	600	24	12	-	-	2.7	55	0.27	1.25	-	-	TO-263 (D2 PAK)
IXGP12N60CD1	600	24	12	-	-	2.7	55	0.27	1.25	12	1.6	TO-220
IXGH12N60C	600	24	12		-	2.7	55	0.27	1.25	-	-	TO-247
IXGA12N60B	600	24	12	-	-	2.1	120	0.8	1.25	-	-	TO-263 (D2 PAK)
IXGP12N60B	600	24	12		-	2.1	120	0.8	1.25	-	-	TO-220
IXGH12N60BD1	600	24	12		-	2.1	120	0.8	1.25	15	1.6	TO-247
IXGP12N60C	600	24	12		-	2.7	55	0.27	1.25	-	-	TO-220
IXGA12N60CD1	600	24	12	-	-	2.7	55	0.27	1.25	-	1.6	TO-263 (D2 PAK)
IXGH12N60CD1	600	24	12	-	-	2.7	55	0.27	1.25	12	1.6	TO-247
IXGH12N60B	600	24	12		-	2.1	120	0.8	1.25	-	-	TO-247
IXGT32N60BD1	600	32	-		-	2.3	85	1.2	0.62	32	1	TO-268
IXGP28N60A3M	600	38	-	-	15	1.4	260	4.2	1.94	-	-	OVERMOLDED TO-220
IXGA16N60B2	600	40	-	-	16	1.95	70	0.38	0.83	-	-	TO-263 (D2 PAK)
IXGP16N60B2D1	600	40	-	-	16	1.95	70	0.38	0.83	11	2.5	TO-220
IXGP16N60B2	600	40	-	-	16	1.95	70	0.38	0.83	-	-	TO-220
IXGH28N60BD1	600	40	28		-	2	200	6	0.83	28	1	TO-247
IXGH16N60C2D1	600	40	-	-	16	3	33	0.27	0.83	11	2.5	TO-247
IXGH28N60B	600	40	28		-	2	200	6	0.83	-	-	TO-247
IXGH20N60B	600	40	20	-	-	2	100	1.2	0.83	-	-	TO-247
IXGA16N60C2	600	40	-		16	3	33	0.27	0.83	-	-	TO-263 (D2 PAK)
IXGA20N60B	600	40	20	-	-	2	100	1.2	0.83	-	-	TO-263 (D2 PAK)
IXGA16N60C2D1	600	40	-	-	16	3	33	0.27	0.83	11	2.5	TO-263 (D2 PAK)
IXGT20N60BD1	600	40	20	-	-	2	100	1.2	0.83	-	1	TO-268
IXGP16N60C2D1	600	40	-	-	16	3	33	0.27	0.83	11	2.5	TO-220
IXGH20N60BD1	600	40	20	-	-	2	100	1.2	0.83	-	1	TO-247
IXGT28N60B	600	40	28		-	2	200	6	0.83	-	-	TO-268
IXGT28N60BD1	600	40	-		28	2	200	6	0.83	1	-	TO-268
IXGA16N60B2D1	600	40	-	-	16	1.95	70	0.38	0.83	11	2.5	TO-263 (D2 PAK)
IXGT20N60B	600	40	20	-	-	2	100	1.2	0.83	-	-	TO-268
IXGP16N60C2	600	40	-	-	16	3	33	0.27	0.83	-	-	TO-220
IXGH16N60B2D1	600	40	-	-	16	1.95	70	0.38	0.83	11	2.5	TO-247
IXGR24N60C	600	42	-		22	2.5	60	0.6	1.57	-	-	ISOPLUS247?
IXGP30N60B2	600	45	-		30	1.8	82	0.9	0.65	-	-	TO-220
IXGR32N60C	600	45	-		26	2.7	55	0.85	0.9	-	-	ISOPLUS247?
IXGH24N60B	600	48	24		-	2.3	80	1.4	0.83	-	-	TO-247
IXGT24N60C	600	48	-		24	2.1	60	0.6	0.83	-	-	TO-268
IXGT32N60CD1	600	48	-	-	32	2.5	55	0.85	0.62	32	0.9	TO-268
IXGP24N60C	600	48	-		24	2.1	60	0.6	0.83	-	-	TO-220
IXGA24N60C	600	48	-	-	24	2.1	60	0.6	0.83	-	-	TO-263 (D2 PAK)
IXGH24N60CD1	600	48	-	-	24	2.1	60	0.6	0.83	24	0.9	TO-247
IXGH24N60C	600	48	-		24	2.1	60	0.6	0.83	-	-	TO-247
IXGT24N60CD1	600	48	-	-	24	2.1	60	0.6	0.83	24	0.9	TO-268
IXGJ50N60C4D1	600	52	-	-	21	2.5	63	0.9	1	12	2	ISO TO-247
IXGH24N60C4D1	600	56	-	-	24	2.7	68	0.5	0.65	18	1.6	TO-247
IXGP24N60C4D1	600	56	-	-	24	2.7	44	0.52	0.65	30	2.5	TO-220
IXGP30N60B4D1	600	56	-	-	30	1.7	88	1.5	0.66	10	2.5	TO-220
IXGR40N60C2	600	56	-	-	26	2.7	32	0.5	0.74	-	-	ISOPLUS247?
IXGR48N60C3D1	600	56	-	-	26	2.7	38	0.57	1	27	1.5	ISOLPUS-247
IXGR40N60C2D1	600	56	-	-	26	2.7	32	0.2	0.74	50	1.5	ISOPLUS247?
IXGP24N60C4	600	56	-	-	24	2.7	68	0.5	0.65	-	-	TO-220
IXGH24N60C4	600	56	-	-	24	2.7	68	0.5	0.65	-	-	TO-247
IXGA24N60C4	600	56	-	-	24	2.7	68	0.5	0.65	-	-	TO-263
IXGP30N60C3D4	600	60	-	-	30	3	47	0.33	0.56	-	2.5	TO-200
IXGP30N60C3C1	600	60	-	-	30	3	47	0.33	0.56	13	1.1	TO-220
IXGA30N60C3	600	60	-	-	30	3	47	0.33	0.56	-	-	TO-263
IXGH32N60CD1	600	60	-	-	32	2.5	55	0.85	0.62	32	0.9	TO-247
IXGH30N60C3D1	600	60	-	-	30	3	47	0.33	0.56	30	0.9	TO-247
IXGH30N60C3C1	600	60	-	-	30	3	47	0.33	0.56	13	1.1	TO-247
IXGH30N60BU1	600	60	-		30	1.8	100	2.5	0.62	30	1	TO-247
IXGH34N60B2	600	60	-		34	1.55	150	1.2	0.65	-	-	TO-247
IXGT31N60D1	600	60	31	-	-	1.7	400	12	0.83	31	1	TO-268
IXGT31N60	600	60	31		-	1.7	400	12	0.83	-	-	TO-268
IXGR40N60B2	600	60	-		33	1.9	82	1.1	0.74	-	-	ISOPLUS247?
IXGR50N60B2D1	600	60	-		36	2.2	65	1.55	0.6	39	0.85	ISOPLUS247?
IXGH31N60	600	60	31		-	1.7	400	12	0.83	-	-	TO-247
IXGP30N60C3	600	60	-		30	3	47	0.33	0.56	-	-	TO-220
IXGH31N60D1	600	60	31	-	-	1.7	400	12	0.83	31	1	TO-247
IXGH32N60C	600	60	-		32	2.5	55	0.85	0.62	-	-	TO-247
IXGT30N60B	600	60	-		30	1.8	100	3	0.62	-	-	TO-268
IXGR48N60B3	600	60	-		27	2.1	116	1.3	0.83	-	-	ISOPLUS247
IXGR50N60B2	600	60	-		36	2.2	82	1.55	0.6	-	-	ISOPLUS247?
IXGH30N60C3	600	60	-		30	3	47	0.33	0.56	-	-	TO-247
IXGT32N60C	600	60	-		32	2.5	55	0.85	0.62	-	-	TO-268
IXGH32N60A	600	60	32		-	2.3	80	1.2	0.62	-	-	TO-247
IXGR40N60B2D1	600	60	-		33	1.9	82	1.1	0.75	25	1.1	ISOPLUS247?
IXGT30N60C3D1	600	60	-	-	30	3	47	0.33	0.56	30	0.9	TO-268
IXGA30N60C3C1	600	60	-	-	30	3	47	0.33	0.56	13	1.1	TO-263
IXGH30N60BD1	600	60	30	-	-	1.8	100	2.5	0.62	30	0.9	TO-247
IXGH30N60B	600	60	-		30	1.8	100	3	0.62	-	-	TO-247
IXGR48N60B3D1	600	60	-		27	2.1	116	1.3	0.83	27	1.5	ISOPLUS247
IXGA30N60C3D4	600	60	-	-	30	3	47	0.33	0.56	-	2.5	TO-263
IXGH32N60BD1	600	64	32		-	2.3	85	1.2	0.62	32	1	TO-247
IXGH32N60BU1	600	64	32		-	2.3	80	1.2	0.62	32	1	TO-247
IXGH32N60B	600	64	32		-	2.3	85	1.2	0.62	-	-	TO-247
IXGR39N60B	600	66	-		35	1.8	200	6	0.9	-	-	ISOPLUS247?
IXGH28N60B3D1	600	66	-		28	1.8	100	1	0.66	10	1	TO-247
IXGH30N60B4	600	66	-	-	30	1.7	88	1.5	0.66	-	-	TO-247
IXGH30N60C2	600	70	-		30	2.5	32	0.4	0.65	-	-	TO-247
IXGT30N60C2D1	600	70	-	-	30	2.7	32	0.4	0.65	30	0.9	TO-268
IXGR40N60BD1	600	70	35		-	2.1	180	4	0.6	35	0.9	ISOPLUS247?
IXGH30N60C2D1	600	70	-	-	30	2.7	32	0.4	0.65	30	0.9	TO-247
IXGH30N60B2	600	70	-		30	1.8	82	0.9	0.65	-	-	TO-247
IXGR40N60B	600	70	35		-	2.1	180	4	0.6	-	-	ISOPLUS247?
IXGP30N60C2	600	70	-		30	2.5	32	0.4	0.65	-	-	TO-220
IXGH30N60B2D1	600	70	-	-	30	1.8	82	0.9	0.42	30	0.9	TO-247
IXGT30N60B2	600	70	-		30	1.8	82	0.9	0.42	-	-	TO-268
IXGT30N60B2D1	600	70	-		30	1.8	82	0.9	0.42	30	0.9	TO-268
IXGT30N60C2	600	70	-		30	2.5	32	0.4	0.65	-	-	TO-268
IXGX50N60A2D1	600	75	-	-	50	1.4	250	4.1	0.31	38	0.65	PLUS247
IXGH28N60A3	600	75	-	-	28	1.4	260	4.2	0.66	-	-	TO-247
IXGR72N60A3	600	75	-	-	52	1.45	250	6.5	0.62	-	-	ISOPLUS247
IXGR60N60B2	600	75	-		47	2	100	2.8	0.5	-	-	ISOPLUS247?
IXGK50N60A2D1	600	75	-	-	50	1.4	250	4.1	0.31	38	0.65	TO-264
IXGT60N60	600	75	60		-	1.7	360	17	0.42	-	-	TO-268
IXGH72N60A3	600	75	-		72	1.35	250	6.5	0.23	-	-	TO-247
IXGT72N60A3	600	75	-		72	1.35	250	6.5	0.23	-	-	TO-268
IXGR60N60U1	600	75	60	-	-	1.7	500	26	0.5	60	1	ISOPLUS247?
IXGR72N60A3H1	600	75	-	-	52	1.45	250	6.5	0.62	32	0.8	ISOPLUS247
IXGR50N60A2U1	600	75	-	-	50	1.8	260	7.7	-	50	0.65	ISOPLUS247?
IXGR50N60B	600	75	-		45	2.5	85	2.5	0.5	-	-	ISOPLUS247?
IXGK72N60A3H1	600	75	-	-	72	1.35	250	6.5	0.23	68	0.3	TO-264
IXGX72N60A3H1	600	75	-	-	72	1.35	250	6.5	0.23	68	0.3	PLUS247
IXGN50N60B	600	75	50		-	2.3	120	4.2	0.42	-	-	SOT-227B
IXGH72N60B3	600	75	-		72	1.8	90	2.2	0.23	-	-	TO-247
IXGH50N60A	600	75	50		-	2.7	275	9.6	0.5	-	-	TO-247
IXGK60N60	600	75	60		-	1.7	360	17	0.42	-	-	TO-264
IXGJ50N60B	600	75	50		-	2.3	120	4.2	0.42	-	-	TO-268 (I3 - PAK)
IXGK50N60B	600	75	50		-	2.3	120	4.2	0.42	-	-	TO-264
IXGH60N60	600	75	60		-	1.7	360	17	0.42	-	-	TO-247
IXGH90N60B3	600	75	-	-	90	1.8	148	2.8	0.19	-	-	TO-247
IXGH60N60B2	600	75	-		60	1.8	100	2.8	0.25	-	-	TO-247
IXGA48N60C3	600	75	-	-	48	2.5	38	0.57	0.42	-	-	TO-263
IXGX60N60B2D1	600	75	-		60	1.8	100	2.8	0.25	48	0.65	PLUS247
IXGP28N60A3	600	75	-	-	28	1.4	260	4.2	0.66	-	-	TO-220
IXGB200N60B3	600	75	-	-	200	1.5	183	4.2	0.1	-	-	PLUS264
IXGH50N60B	600	75	50		-	2.3	120	4.2	0.42	-	-	TO-247
IXGH50N60B2	600	75	-		50	2	82	1.55	0.31	-	-	TO-247
IXGH40N60B	600	75	-		40	2.1	180	4	0.5	-	-	TO-247
IXGH40N60B2	600	75	-		40	1.7	82	1.1	0.42	-	-	TO-247
IXGX40N60BD1	600	75	-		40	1.7	82	1.1	0.31	30	0.9	PLUS247
IXGX50N60B2D1	600	75	-		50	2	65	1.55	0.25	48	0.65	PLUS247
IXGK60N60B2D1	600	75	-		60	1.8	100	2.8	0.25	48	0.65	TO-264
IXGT40N60B2D1	600	75	-		40	1.7	82	1.1	0.31	30	0.9	TO-268
IXGT50N60C2	600	75	-	-	50	2.7	48	0.74	0.31	-	-	TO-268
IXGT60N60C2	600	75	-		60	2.5	35	1.2	0.26	-	-	TO-268
IXGX120N60C2	600	75	-		120	2.5	80	1.24	0.15	-	-	PLUS247
IXGK50N60BD1	600	75	50		-	2.3	85	2.5	0.42	50	0.65	TO-264
IXGJ40N60C2D1	600	75	-	-	40	2.7	32	0.5	0.42	40	0.9	TO-268 (I3 - PAK)
IXGK50N60B2D1	600	75	-		50	2	65	1.55	0.25	48	0.65	TO-264
IXGH48N60C3	600	75	-		48	2.5	38	0.57	0.42	-	-	TO-247
IXGH40N60C2D1	600	75	-	-	40	2.7	32	0.5	0.42	40	0.9	TO-247
IXGH48N60C3C1	600	75	-	-	48	2.5	38	0.57	0.42	20	0.9	TO-247
IXGH50N60C2	600	75	-	-	50	2.7	48	0.74	0.31	-	-	TO-247
IXGT40N60C2	600	75	-		40	2.7	32	0.5	0.42	-	-	TO-268
IXGR72N60B3D1	600	75	-		40	1.8	90	2.2	0.62	36	0.85	ISOLPUS-247
IXGR60N60B2D1	600	75	-		47	2	100	2.8	0.5	39	0.85	ISOPLUS247?
IXGP48N60C3	600	75	-		48	2.5	38	0.57	0.42	-	-	TO-220
IXGH72N60C3	600	75	-		72	2.5	55	0.93	0.23	-	-	TO-247
IXGI48N60C3	600	75	-		48	2.5	-	0.57	0.42	-	-	TO-263 LEAD
IXGK120N60C2	600	75	-		120	2.5	80	1.24	0.15	-	-	TO-246
IXGN60N60C2	600	75	-		60	2.5	35	1.2	0.26	-	-	SOT-227B
IXGR50N60BD1	600	75	-		45	2.3	85	2.5	0.5	45	0.65	ISOPLUS247?
IXGR60N60C2	600	75	-		48	2.7	35	0.5	0.32	-	-	ISOPLUS247?
IXGH60N60C2	600	75	-	-	60	2.5	35	1.2	0.26	-	-	TO-247
IXGT40N60C	600	75	-		40	2.7	75	1.2	0.5	-	-	TO-268
IXGR50N60C2	600	75	-	-	36	2.7	48	0.74	0.62	-	-	ISOPLUS247?
IXGR120N60C2	600	75	-		60	2.7	80	1.24	0.42	-	-	ISOPLUS247
IXGR40N60C	600	75	-		35	2.5	75	1.2	0.6	-	-	ISOPLUS247?
IXGH60N60C3	600	75	-		60	2.5	50	0.8	0.33	-	-	TO-247
IXGX60N60C2D1	600	75	-	-	60	2.5	35	1.2	0.26	48	0.65	PLUS247
IXGX72N60C3H1	600	75	-	-	72	2.5	55	0.93	0.23	-	0.3	PLUS247
IXGX50N60BD1	600	75	50		-	2.3	85	2.5	0.42	50	0.65	PLUS247
IXGX50N60C2D1	600	75	-	-	50	2.7	48	0.74	0.31	48	0.65	PLUS247
IXGR72N60C3D1	600	75	-	-	35	2.7	55	0.93	0.62	36	0.85	ISOLPUS-247
IXGT40N60C2D1	600	75	-	-	40	2.7	32	0.5	0.42	40	0.9	TO-268
IXGT60N60C3D1	600	75	-	-	60	2.5	50	0.8	0.33	26	0.9	TO-268
IXGT72N60B3	600	75	-		72	1.8	90	2.2	0.23	-	-	TO-268
IXGT40N60B2	600	75	-		40	1.7	82	1.1	0.42	-	-	TO-268
IXGT40N60B	600	75	-		40	2.1	180	4	0.5	-	-	TO-268
IXGT50N60B	600	75	50		-	2.3	120	4.2	0.42	-	-	TO-268
IXGA28N60A3	600	75	-	-	28	1.4	260	4.2	0.66	-	-	TO-263
IXGT60N60B2	600	75	-		60	1.8	100	2.8	0.25	-	-	TO-268
IXGT50N60B2	600	75	-		50	2	82	1.55	0.31	-	-	TO-268
IXGR60N60C3D1	600	75	-	-	30	2.5	50	0.8	0.73	17	1.5	ISOLPUS-247
IXGN60N60C2D1	600	75	-	-	60	2.5	35	1.2	0.26	-	0.85	SOT-227B
IXGH40N60C2	600	75	-	-	40	2.7	32	0.5	0.42	-	-	TO-247
IXGH40N60C	600	75	-		40	2.7	75	1.2	0.5	-	-	TO-247
IXGH40N60B2D1	600	75	-		40	1.7	82	1.1	0.31	30	0.9	TO-247
IXGH48N60B3C1	600	75	-		48	1.8	116	1.3	0.42	20	0.9	TO-247
IXGK50N60C2D1	600	75	-	-	50	2.7	48	0.74	0.31	48	0.65	TO-264
IXGK60N60C2D1	600	75	-	-	60	2.5	35	1.2	0.26	48	0.65	TO-264
IXGH36N60B3C1	600	75	-		36	1.8	100	1.5	0.5	20	0.9	TO-247
IXGR60N60C2C1	600	75	-	-	39	2.7	54	1.2	0.5	14	1.75	ISOPLUS247
IXGR60N60C2D1	600	75	-	-	48	2.7	35	1.2	0.65	60	0.85	ISOPLUS247?
IXGR60N60C3C1	600	75	-	-	30	2.5	50	0.8	0.73	13	1.75	ISOPLUS247
IXGR40N60CD1	600	75	-	-	35	2.5	75	1.2	0.6	35	0.9	ISOPLUS247?
IXGR50N60C2D1	600	75	-	-	36	2.7	48	0.74	0.62	42	0.85	ISOPLUS247?
IXGR60N60C2C1	600	75	-	-	39	2.7	54	1.2	0.5	14	1.75	ISOPLUS247
IXGT39N60BD1	600	76	39		-	1.7	200	6	0.62	39	0.9	TO-268
IXGH41N60	600	76	41		-	1.6	450	15	0.62	-	-	TO-247
IXGT39N60B	600	76	39		-	1.7	200	6	0.62	-	-	TO-268
IXGH39N60BD1	600	76	39		-	1.7	200	6	0.62	39	0.9	TO-247
IXGH39N60B	600	76	39		-	1.7	200	6	0.62	-	-	TO-247
IXGN72N60C3H1	600	78	-	-	52	2.5	55	0.93	0.35	-	0.42	SOT-227B
IXGR72N60B3H1	600	80	-	-	40	1.8	92	2.2	0.62	34	0.8	ISOPLUS247
IXGR72N60C3	600	80	-	-	35	2.7	55	-	0.62	-	-	ISOPLUS247
IXGH50N60C4D1	600	90	-	-	46	2.3	63	0.9	0.42	18	1.6	TO-247
IXGA50N60C4	600	90	-	-	46	2.3	63	0.9	0.42	-	-	TO-263
IXGH50N60C4	600	90	-	-	46	2.3	63	0.9	0.42	-	-	TO-247
IXGP50N60C4	600	90	-	-	46	2.3	63	0.9	0.42	-	-	TO-220
IXGQ50N60C4D1	600	90	-	-	46	2.3	63	0.9	0.42	18	1.6	TO-3P
IXGH36N60B3	600	92	-		36	1.8	100	1.5	0.5	-	-	TO-247
IXGH50N60B4D1	600	100	-	-	50	1.8	80	1.9	0.42	18	1.6	TO-247
IXGN60N60	600	100	60		-	1.7	360	17	0.5	-	-	SOT-227B
IXGP50N60B4	600	100	-	-	50	1.8	80	1.9	0.42	-	-	TO-220
IXGQ50N60B4D1	600	100	-	-	50	1.8	80	1.9	0.42	18	1.6	TO-3P
IXGH50N60B4	600	100	-	-	50	1.8	80	1.9	0.42	-	-	TO-247
IXGA50N60B4	600	100	-	-	50	1.8	80	1.9	0.42	-	-	TO-263
IXGB75N60BD1	600	120	75	-	-	2.3	150	6	0.35	75	0.65	PLUS264
IXGH56N60B3	600	130	0		56	1.8	95	2.2	0.375	0	0	TO-247
IXGH56N60A3	600	150	0		56	1.35	315	6.75	0.375	0	0	TO-247
IXGL200N60B3	600	150	-	-	90	1.5	183	2.9	0.31	-	-	ISOPLUS264
IXGR120N60B	600	156	-		80	2.1	160	8.7	0.3	-	-	ISOPLUS247?
IXGN72N60A3	600	160	-		68	1.35	250	6.5	0.35	-	-	SOT-227B
IXGE200N60B	600	175	112	-	-	2.1	160	8.7	0.25	-	-	ISOPLUS227?
IXGK72N60B3H1	600	178	-	-	72	1.8	92	1	0.23	-	0.3	TO-264
IXGX72N60B3H1	600	178	-	-	72	1.8	92	1	0.23	-	0.3	PLUS247
IXGN200N60B	600	200	-		120	2.1	160	8.7	0.21	-	-	SOT-227B
IXGN120N60A3	600	200	-		120	1.35	260	10.4	0.21	-	-	SOT-227B
IXGN200N60A2	600	200	-		100	1.35	250	12	0.17	-	-	SOT-227B
IXGX120N60B	600	200	120		-	2.1	160	5.5	0.19	-	-	PLUS247
IXGK120N60A3	600	200	-		120	1.35	260	10.4	0.16	-	-	TO-264
IXGX120N60B	600	200	120		-	2.1	160	8.7	0.19	-	-	PLUS247
IXGK120N60B	600	200	120		-	2.1	160	8.7	0.19	-	-	TO-264
IXGK120N60B	600	200	120		-	2.1	160	5.5	0.19	-	-	TO-264
IXGH36N60B3D1	600	200	-		36	1.8	100	1.5	0.5	30	0.9	TO-247
IXGN120N60A3D1	600	200	-	-	120	1.35	260	10.4	0.21	36	0.85	SOT-227B
IXGH36N60B3D4	600	200	-		36	1.8	100	1.5	0.5	10	2.5	TO-247
IXGX120N60A3	600	200	-	-	120	1.35	260	10.4	0.16	-	-	PLUS-247
IXGA48N60B3	600	280	-	-	48	1.8	116	1.3	0.42	-	-	TO-263
IXGK120N60B3	600	280	-		120	1.8	145	4.7	0.16	-	-	TO-264
IXGH48N60B3	600	280	-		48	1.8	116	1.3	0.42	-	-	TO-247
IXGX120N60B3	600	280	-		120	1.8	145	4.7	0.16	-	-	PLUS247
IXGP48N60B3	600	280	-		48	1.8	116	1.3	0.42	-	-	TO-220
IXGN200N60B3	600	300	-		200	1.5	183	4.2	0.15	-	-	SOT-227B
IXGX320N60A3	600	320	-	-	210	1.3	-	-	0.125	-	-	PLUS247
IXGN320N60A3	600	320	-	-	170	1.3	-	-	0.17	-	-	SOT-227B
IXGK320N60A3	600	320	-	-	210	1.3	-	-	0.125	-	-	TO-264
IXGK320N60B3	600	320	-		170	1.6	185	5	0.125	-	-	TO-264
IXGH56N60B3D1	600	350	-	-	56	1.8	95	2.2	0.375	-	0.9	TO-247
IXGN400N60A3	600	400	0	-	190	1.25	0	0	0.15	0	0	SOT-227
IXGX64N60B3D1	600	400	-		64	1.8	88	1.95	0.27	-	1.35	PLUS247
IXGK64N60B3D1	600	400	-		64	1.8	88	1.95	0.27	-	1.35	TO-264
IXGN400N60B3	600	430	-	-	200	1.5	125	4.25	0.125	-	-	SOT-227B
IXGX320N60B3	600	500	320		-	1.6	165	5.4	0.073	-	-	PLUS247
IXGK320N60B3	600	500	320		-	1.6	165	5.4	0.073	-	-	TO-264
IXGH48N60A3	600	-	-		48	1.35	224	5.6	0.42	-	-	TO-247
IXGA48N60A3	600	-	-	-	48	1.35	224	5.6	0.42	-	-	TO-263
IXGH36N60A3	600	-	-	-	36	1.4	325	5.3	0.56	-	-	TO-247
IXGH48N60B3D1	600	-	-		48	1.8	116	1.3	0.42	-	1.5	TO-247
IXGT64N60B3	600	-	-		-	1.8	88	1.95	0.27	-	-	TO-268
IXGH64N60B3	600	-	-		-	1.8	88	1.95	0.27	-	-	TO-247
IXGH64N60A3	600	-	-		64	1.35	222	6	0.27	-	-	TO-247
IXGA36N60A3	600	-	-	-	36	1.4	325	5.3	0.56	-	-	TO-263
IXGP36N60A3	600	-	-	-	36	1.4	325	5.3	0.56	-	-	TO-220
IXGH36N60A3D4	600	-	-	-	36	1.4	325	5.3	0.56	10	2.5	TO-247
IXGT64N60A3	600	-	-		64	1.35	222	6	0.27	-	-	TO-268
IXGR64N60A3	600	-	-		47	1.35	222	6.03	0.62	-	-	ISOPLUS247
IXGP48N60A3	600	-	-		48	1.35	224	5.6	0.42	-	-	TO-220
IXGX12N90C	900	24	12		-	3	70	0.7	1.25	-	-	PLUS247
IXGH12N90C	900	24	12		-	3	70	0.7	1.25	-	-	TO-247
IXGR50N90B2D1	900	40	-		19	2.9	200	8.7	1.25	22	1.1	ISOPLUS247?
IXGR32N90B2D1	900	47	-		22	2.9	165	5.25	0.8	22	1.1	ISOPLUS247?
IXGT28N90B	900	51	-		28	2.7	130	2.5	0.62	-	-	TO-268
IXGH28N90B	900	51	-		28	2.7	130	2.5	0.62	-	-	TO-247
IXGH32N90B2D1	900	64	-		32	2.7	165	5.25	0.42	27	0.9	TO-247
IXGT32N90B2	900	64	-		32	2.7	165	5.25	0.42	-	-	TO-268
IXGT32N90B2D1	900	64	-		32	2.7	165	5.25	0.42	27	0.9	TO-268
IXGH32N90B2	900	64	-		32	2.7	165	5.25	0.42	-	-	TO-247
IXGH50N90B2D1	900	75	-		50	2.7	200	8.7	0.31	15	0.9	TO-247
IXGH50N90B2	900	75	-		50	2.7	200	8.7	0.31	-	-	TO-247
IXGT50N90B2	900	75	-		50	2.7	200	8.7	0.31	-	-	TO-268
IXGK50N90B2D1	900	75	-		50	2.7	200	8.7	0.31	15	0.9	TO-264
IXGX50N90B2D1	900	75	-		50	2.7	200	8.7	0.31	15	0.9	PLUS247
IXGP2N100A	1000	4	2		-	3.5	180	0.5	5	-	-	TO-220
IXGP2N100	1000	4	2	-	-	2.7	560	1	5	-	-	TO-220
IXGA4N100	1000	8	4	-	-	2.7	340	2	3.1	-	-	TO-263 (D2 PAK)
IXGP4N100	1000	8	4		-	2.7	340	2	3.1	-	-	TO-220
IXGA8N100	1000	16	8	-	-	2.7	390	3.7	2.3	-	-	TO-263 (D2 PAK)
IXGP8N100	1000	16	8	-	-	3	390	3.7	2.3	-	-	TO-220
IXGH12N100AU1	1000	24	12	-	-	4	950	8	1.25	8	2.5	TO-247
IXGP12N100U1	1000	24	12	-	-	3.5	800	10	1.25	12	2.5	TO-220
IXGH12N100U1	1000	24	12	-	-	3.5	800	10	1.25	12	2.5	TO-247
IXGH12N100A	1000	24	12		-	4	500	2.2	1.25	-	-	TO-247
IXGA12N100U1	1000	24	12	-	-	3.5	800	10	1.25	12	2.5	TO-263 (D2 PAK)
IXGA12N100AU1	1000	24	12	-	-	4	950	8	1.25	8	2.5	TO-263 (D2 PAK)
IXGA12N100	1000	24	12		-	3.5	800	6	1.25	-	-	TO-263 (D2 PAK)
IXGA12N100A	1000	24	12	-	-	4	500	2.2	1.25	-	-	TO-263 (D2 PAK)
IXGP12N100AU1	1000	24	12	-	-	4	500	8	1.25	8	2.5	TO-220
IXGH12N100	1000	24	12		-	3.5	800	6	1.25	-	-	TO-247
IXGP12N100	1000	24	12		-	3.5	800	6	1.25	-	-	TO-220
IXGP12N100A	1000	24	12		-	4	500	2.2	1.25	-	-	TO-220
IXGP15N100C	1000	30	15		-	3.5	115	1.85	0.83	-	-	TO-220
IXGA15N100C	1000	30	15	-	-	3.5	115	1.85	0.83	-	-	TO-263 (D2 PAK)
IXGH17N100AU1	1000	34	17	-	-	4	450	6	0.83	17	1	TO-247
IXGM17N100A	1000	34	17		-	4	450	6	0.83	-	-	TO-204
IXGM17N100	1000	34	17		-	3.5	750	8	0.83	-	-	TO-204
IXGH17N100	1000	34	17		-	3.5	750	8	0.83	-	-	TO-247
IXGH17N100U1	1000	34	17	-	-	3.5	750	8	0.83	17	1	TO-247
IXGH17N100A	1000	34	17		-	4	450	6	0.83	-	-	TO-247
IXGH20N100A3	1000	40	20		-	2.3	-	-	0.83	-	-
IXGP20N100	1000	40	20		-	3	280	3.5	0.83	-	-	TO-220
IXGH20N100	1000	40	20		-	3	280	3.5	0.83	-	-	TO-247
IXGP20N100A3	1000	40	20		-	2.3	-	-	0.83	-	-
IXGA20N100	1000	40	20	-	-	3	280	3.5	0.83	-	-	TO-263 (D2 PAK)
IXGT20N100	1000	40	20		-	3	280	3.5	0.83	-	-	TO-268
IXGA20N100A3	1000	40	20	-	-	2.3	-	-	0.83	-	-	TO-263
IXGH25N100A	1000	50	25		-	4	500	8	0.62	-	-	TO-247
IXGH25N100AU1	1000	50	25	-	-	4	500	6	0.62	25	1	TO-247
IXGH25N100	1000	50	25		-	3.5	500	10	0.62	-	-	TO-247
IXGM25N100A	1000	50	25		-	4	500	8	0.62	-	-	TO-204
IXGH25N100U1	1000	50	25	-	-	3.5	-	10	0.62	25	1	TO-247
IXGT32N100A3	1000	75	-		32	2.2	540	13	0.42	-	-	TO-268
IXGH32N100A3	1000	75	-	-	32	2.2	540	13	0.42	-	-	TO-247
IXGY2N120	1200	5	2	-	-	3	360	1.2	4.2	-	-	TO-252AA (D PAK)
IXGP12N120A3	1200	22	12			3			1.25			TO-220
IXGA12N120A3	1200	22	12	-	-	3	-	-	1.25	-	-	TO-263
IXGH12N120A3	1200	22	12	-	-	3	-	-	1.25	-	-	TO-247
IXGA12N120A2	1200	24	-	-	12	3	650	7.7	1.66	-	-	TO-263 (D2 PAK)
IXGP12N120A2	1200	24	-		12	3	650	7.7	1.66	-	-	TO-220
IXGA14N120B	1200	28	-	-	14	3.3	330	4.85	0.83	-	-	TO-263 (D2 PAK)
IXGP14N120B	1200	28	-	-	14	3.3	330	4.85	0.83	-	-	TO-220
IXGP15N120B	1200	30	-	-	15	3.2	160	3.5	0.83	-	-	TO-220
IXGH15N120BD1	1200	30	15	-	-	3.2	160	3.5	0.83	15	1.6	TO-247
IXGH15N120CD1	1200	30	15	-	-	3.8	115	2.1	0.83	15	1.6	TO-247
IXGT15N120B2D1	1200	30	15		-	3.3	137	2.8	0.65	-	1.6	TO-268
IXGP15N120B2	1200	30	15		-	3.5	137	2.8	0.75	-	-	TO-220
IXGH15N120B2D1	1200	30	15		-	3.3	137	2.8	0.65	-	1.6	TO-247
IXGT15N120BD1	1200	30	15	-	-	3.2	160	3.5	0.83	15	1.6	TO-268
IXGT15N120B	1200	30	-	-	15	3.2	160	3.5	0.65	-	-	TO-268
IXGA15N120B2	1200	30	15	-	-	3.5	137	2.8	0.75	-	-	TO-263
IXGH15N120C	1200	30	15		-	3.8	115	2.1	0.83	-	-	TO-247
IXGH15N120B	1200	30	-	-	15	3.2	160	3.5	0.65	-	-	TO-247
IXGT15N120C	1200	30	15		-	3.8	115	2.1	0.83	-	-	TO-268
IXGT15N120CD1	1200	30	15	-	-	3.8	115	2.1	0.83	15	1.6	TO-268
IXGP15N120C	1200	30	15		-	3.8	115	2.1	0.83	-	-	TO-220
IXGA15N120C	1200	30	15	-	-	3.8	115	2.1	0.83	-	-	TO-263 (D2 PAK)
IXGA15N120B	1200	30	-	-	15	3.2	160	3.5	0.83	-	-	TO-263 (D2 PAK)
IXGP20N120B3	1200	36	20	-	-	3.1	155	1.63	0.69	-	-	TO-220
IXGA20N120B3	1200	36	20	-	-	3.1	155	1.63	0.69	-	-	TO-263
IXGT20N120B	1200	40	-		20	3.4	160	3.5	0.65	-	-	TO-268
IXGA20N120A3	1200	40	-	-	20	2.5	715	10.1	0.69	-	-	TO-263
IXGH20N120B	1200	40	-		20	3.4	160	3.5	0.65	-	-	TO-247
IXGH20N120A3	1200	40	-		20	2.5	715	10.1	0.69	-	-	TO-247
IXGH20N120	1200	40	20	-	-	2.5	380	6.5	0.83	-	-	TO-247
IXGQ20N120B	1200	40	-		20	3.4	160	3.5	0.65	-	-	TO-3P
IXGP20N120	1200	40	20	-	-	2.5	380	6.5	0.83	-	-	TO-220
IXGP20N120A3	1200	40	-		20	2.5	715	10.1	0.69	-	-	TO-220
IXGA20N120	1200	40	20	-	-	2.5	380	6.5	0.83	-	-	TO-263 (D2 PAK)
IXGT20N120	1200	40	20		-	3	280	6.5	0.83	-	-	TO-268
IXGP24N120C3	1200	48	-		-	4.2	110	1.18	0.5	-	-	TO-220
IXGH24N120C3H1	1200	48	-	-	-	4.2	110	1.18	0.5	-	0.9	TO-247
IXGH30N120C3H1	1200	48	-	-	-	4.2	42	1.3	0.5	-	0.9	TO-247
IXGA24N120C3	1200	48	-	-	-	4.2	110	1.18	0.5	-	-	TO-263
IXGR24N120C3D1	1200	48	-	-	-	4.2	110	1.18	1	-	-	ISOLPUS-247
IXGH24N120C3	1200	48	-		-	4.2	110	1.18	0.5	-	-	TO-247
IXGH28N120BD1	1200	50	-	-	-	3.5	170	4.6	0.5	10	2.5	TO-247
IXGH30N120B3D1	1200	50	-		30	3.5	204	5.1	0.42	28	0.9	TO-247
IXGT28N120B	1200	50	-		28	3.5	160	5	0.5	-	-	TO-268
IXGH25N120	1200	50	25		-	3	700	15	0.62	-	-	TO-247
IXGT28N120BD1	1200	50	-	-	-	3.5	170	4.6	0.5	10	2.5	TO-268
IXGH28N120B	1200	50	-		28	3.5	160	5	0.5	-	-	TO-247
IXGT30N120B3D1	1200	50	-		30	3.5	204	5.1	0.42	28	0.9	TO-268
IXGR35N120BD1	1200	54	-		28	3.5	160	8	0.5	8	2.5	ISOPLUS247?
IXGP30N120B3	1200	60	-		30	3.5	204	5.1	0.42	-	-	TO-220
IXGA30N120B3	1200	60	-	-	30	3.5	204	5.1	0.42	-	-	TO-263
IXGH30N120B3	1200	60	-		30	3.5	204	5.1	0.42	-	-	TO-247
IXGH35N120B	1200	70	-	-	35	3.3	160	8	0.42	-	-	TO-247
IXGK35N120BD1	1200	70	35	-	-	3.3	160	8	0.35	35	0.65	TO-264
IXGT35N120C	1200	70	35		-	4	115	6.2	0.42	-	-	TO-268
IXGR35N120C	1200	70	35		-	4	115	6.2	0.5	-	-	ISOPLUS247?
IXGK35N120B	1200	70	-		35	3.3	160	8	0.35	-	-	TO-264
IXGK35N120C	1200	70	35		-	4	115	6.2	0.42	-	-	TO-264
IXGX35N120CD1	1200	70	35	-	-	3.3	160	8	0.35	35	0.65	PLUS247
IXGX35N120BD1	1200	70	35		-	3.3	160	8	0.35	35	0.65	PLUS247
IXGX35N120B	1200	70	-		35	3.3	160	8	0.35	-	-	PLUS247
IXGT35N120B	1200	70	-		35	3.3	160	8	0.42	-	-	TO-268
IXGR55N120A3H1	1200	70	-	-	30	2.35	282	29	0.62	44	0.42	ISOPLUS247
IXGH35N120C	1200	70	35		-	4	115	6.2	0.42	-	-	TO-247
IXGX35N120C	1200	70	35		-	4	115	6.2	0.42	-	-	PLUS247
IXGK35N120CD1	1200	70	35	-	-	3.3	160	8	0.35	35	0.65	TO-264
IXGR35N120B	1200	70	-		23	3.3	160	8	0.5	-	-	ISOPLUS247?
IXGH40N120C3	1200	75	-		-	4.4	57	1.6	0.33	-	-	TO-247
IXGT45N120	1200	75	45		-	2.5	390	25	0.42	-	-	TO-268
IXGH32N120A3	1200	75	32		-	2.35	1240	-	0.42	-	-	TO-247
IXGH50N120C3	1200	75	-		-	4.2	64	2.1	0.27	-	-	TO-247
IXGH40N120C3D1	1200	75	-	-	40	4.4	57	1.6	0.33	25	0.9	TO-247
IXGT32N120A3	1200	75	32		-	2.35	1240	-	0.42	-	-	TO-268
IXGT40N120B2D1	1200	75	-		40	3.5	140	8.3	0.33	25	0.9	TO-268
IXGT40N120A2	1200	75	-		40	2	800	35	0.35	-	-	TO-268
IXGH45N120	1200	75	45		-	2.5	390	25	0.42	-	-	TO-247
IXGH40N120B2D1	1200	75	-		40	3.5	140	8.3	0.33	25	0.9	TO-247
IXGH40N120A2	1200	75	-		40	2	800	35	0.35	-	-	TO-247
IXGK50N120C3H1	1200	95	-	50	-	4.2	64	2.1	0.27	58	0.3	TO-264
IXGX50N120C3H1	1200	95	-	50	-	4.2	64	2.1	0.27	58	0.3	PLUS247
IXGN50N120C3H1	1200	95	-	-	50	4.2	64	2.1	0.27	58	0.3	SOT-227
IXGX55N120A3H1	1200	125	-	-	55	2.3	282	29	0.27	-	0.42	PLUS247
IXGK55N120A3H1	1200	125	-	-	55	2.3	282	29	0.27	-	0.42	TO-264
IXGN82N120C3H1	1200	130	-	-	58	3.9	100	4	0.21	42	0.42	SOT-227
IXGN82N120B3H1	1200	145	-	-	64	3.2	100	7.1	0.21	42	0.42	SOT-227
IXGX120N120B3	1200	200	120		-	3	145	10.3	0.15	-	-	PLUS247
IXGK120N120B3	1200	200	120		-	3	145	10.3	0.15	-	-	TO-264
IXGK82N120B3	1200	230	-		82	3.2	100	7.1	0.1	-	-	TO-264
IXGX82N120B3	1200	230	-		82	3.2	100	7.1	0.1	-	-	PLUS247
IXGX120N120A3	1200	240	-		120	2.2	325	58	0.15	-	-	PLUS-247
IXGK120N120A3	1200	240	-		120	2.2	325	58	0.15	-	-	TO-264
IXGK82N120A3	1200	260	0		82	2.05	780	22.5	0.1	0	0	TO-264
IXGX82N120A3	1200	260			82	2.05	780	22.5	0.1			PLUS247
IXGT20N140C3H1	1400	42	-	-	-	5	32	1.64	0.5	-	0.9	TO-268
IXGH20N140C3H1	1400	42	-	-	-	5	32	1.64	0.5	-	0.9	TO-247
IXGX28N140B3H1	1400	60	-		28	3.6	360	6.5	0.42	15	0.9	PLUS247
IXGK28N140B3H1	1400	60	-		28	3.6	360	6.5	0.42	15	0.9	TO-264

PartNumber	VDSS	ID(cont)	RDS(on)	Ciss	Qg	trr	trr	PD	RthJC	Package
	Max	TC=25°C	max	Typ	Typ	Typ	Max	(W)	Max	Style
	(V)	(A)	TJ=25°C	(pF)	(nC)	(ns)	(ns)		(oC/W)
			(?)
IXFK102N30P	300	102	0.033	7500	224	-	200	700	0.18	TO-264
IXFK140N30P	300	140	0.024	14800	185	-	200	1040	0.12	TO-264
IXFH44N50P	500	44	0.14	5440	98	-	200	658	0.19	TO-247
IXFH50N50P3	500	50	0.125	4335	85	-	250	960	0.13	TO-247
IXFK94N50P2	500	94	0.055	14200	228	-	250	1300	0.096	TO-264
IXFK98N50P3	500	98	0.05	12900	200	-	250	1300	0.096	TO-264
IXFH28N60P3	600	28	0.26	3560	50	-	250	695	0.18	TO-247
IXFK44N80P	800	44	0.19	12000	198	-	250	1200	0.12	TO-264
IXFH12N90P	900	12	1	3080	56	-	300	380	0.33	TO-247
IXFX180N07	70	180	0.006	11080	395	-	250	568	0.22	PLUS247
IXFK180N07	70	180	0.006	11080	395	-	250	568	0.22	TO-264
IXFR180N07	70	180	0.006	11080	395	-	250	417	0.3	ISOPLUS247?
IXFN340N07	70	340	0.004	12200	490	-	200	694	0.18	SOT-227B
IXFH110N10P	100	110	0.015	3550	110	-	150	480	0.31	TO-247
IXFR200N10P	100	120	0.009	7600	235	-	150	300	0.5	ISOPLUS247?
IXFH140N10P	100	140	0.011	4700	155	-	150	600	0.25	TO-247
IXFT140N10P	100	140	0.011	4700	155	-	150	600	0.25	TO-268
IXFK170N10P	100	170	0.009	6000	198	-	150	715	0.21	TO-264
IXFH170N10P	100	170	0.009	6000	198	-	150	715	0.21	TO-247
IXFN180N10	100	180	0.008	10900	390	-	250	600	0.21	SOT-227B
IXFK180N10	100	180	0.008	10900	390	-	250	560	0.22	TO-264
IXFK200N10P	100	200	0.0075	7600	235	-	150	830	0.18	TO-264
IXFX200N10P	100	200	0.0075	7600	235	-	150	830	0.18	PLUS247
IXFN200N10P	100	200	0.0075	7600	235	-	150	680	0.22	SOT-227B
IXFN230N10	100	230	0.006	19000	570	-	250	700	0.18	SOT-227B
IXFX250N10P	100	250	0.0065	16000	205	-	200	1250	0.12	PLUS247
IXFK250N10P	100	250	0.0065	16000	205	-	200	1250	0.12	TO-264
IXFN300N10P	100	295	0.0055	23000	279	-	200	1070	0.14	SOT-227B
IXFB300N10P	100	300	0.0055	23000	279	-	200	1500	0.1	PLUS264
IXFH96N15P	150	96	0.024	3500	110	-	200	480	0.31	TO-247
IXFR180N15P	150	100	0.013	7000	240	-	200	300	0.5	ISOPLUS247?
IXFH120N15P	150	120	0.016	4900	150	-	200	600	0.25	TO-247
IXFT120N15P	150	120	0.016	4900	150	-	200	600	0.25	TO-268
IXFH150N15P	150	150	0.013	5800	190	-	200	714	0.21	TO-247
IXFK150N15P	150	150	0.013	5800	190	-	200	714	0.21	TO-264
IXFN180N15P	150	150	0.011	7000	240	-	200	680	0.22	SOT-227B
IXFK180N15P	150	180	0.011	7000	240	-	200	830	0.18	TO-264
IXFX180N15P	150	180	0.011	7000	240	-	200	830	0.18	PLUS247
IXFX220N15P	150	220	0.009	15400	162	-	200	1250	0.12	PLUS247
IXFK220N15P	150	220	0.009	15400	162	-	200	1250	0.12	TO-264
IXFH70N20Q3	200	70	0.04	3150	67	-	250	690	0.18	TO-247
IXFT70N20Q3	200	70	0.04	3150	67	-	250	690	0.18	TO-268
IXFH74N20P	200	74	0.034	3300	107	-	200	480	0.31	TO-247
IXFR140N20P	200	90	0.022	7500	240	-	200	300	0.5	ISOPLUS247?
IXFH96N20P	200	96	0.024	4800	145	-	200	600	0.25	TO-247
IXFT96N20P	200	96	0.024	4800	145	-	200	600	0.25	TO-268
IXFN140N20P	200	115	0.018	7500	240	-	200	680	0.22	SOT-227B
IXFH120N20P	200	120	0.022	6000	152	100	200	714	0.21	TO-247
IXFK120N20P	200	120	0.022	6000	152	100	200	714	0.21	TO-264
IXFK140N20P	200	140	0.018	7500	240	-	200	830	0.18	TO-264
IXFK170N20P	200	170	0.014	11400	185	-	200	1250	0.12	TO-264
IXFX170N20P	200	170	0.014	11400	185	-	200	1250	0.12	PLUS247
IXFN210N20P	200	188	0.0105	18600	255	-	200	1070	0.14	SOT-227
IXFB210N20P	200	210	0.0105	18600	255	-	200	1500	0.1	PLUS264
IXFK60N25Q	250	60	0.047	5100	180	-	250	357	0.35	TO-264
IXFH100N25P	250	100	0.027	6300	185	-	200	600	0.21	TO-247
IXFX120N25P	250	120	0.024	8700	185	-	200	700	0.18	PLUS247
IXFK120N25P	250	120	0.024	8700	185	-	200	700	0.18	TO-264
IXFP36N30P3	300	36	0.11	2040	30	125	-	347	0.36	TO-220
IXFA36N30P3	300	36	0.11	2040	30	125	-	347	0.36	TO-263
IXFH50N30Q3	300	50	0.08	3160	65	-	250	690	0.18	TO-247
IXFT50N30Q3	300	50	0.08	3160	65	-	250	690	0.18	TO-268
IXFH52N30Q	300	52	0.06	5300	150	-	250	357	0.35	TO-247
IXFH52N30P	300	52	0.073	3490	110	160	200	400	0.31	TO-247
IXFR102N30P	300	60	0.036	7500	224	-	200	250	0.5	ISOPLUS247?
IXFH69N30P	300	69	0.049	4960	156	100	200	500	0.25	TO-247
IXFT69N30P	300	69	0.049	4960	156	100	200	500	0.25	TO-268
IXFT70N30Q3	300	70	0.054	4735	98	-	250	830	0.15	TO-268
IXFH70N30Q3	300	70	0.054	4735	98	-	250	830	0.15	TO-247
IXFR140N30P	300	70	0.026	14800	185	-	200	360	0.35	ISOPLUS247?
IXFN102N30P	300	86	0.033	7500	224	-	200	570	0.22	SOT-227
IXFT88N30P	300	88	0.04	6300	180	-	200	600	0.21	TO-268
IXFH88N30P	300	88	0.04	6300	180	-	200	600	0.21	TO-247
IXFK88N30P	300	88	0.04	6300	180	-	200	600	0.21	TO-264
IXFH94N30P3	300	94	0.036	5510	102	-	250	1040	0.12	TO-247
IXFT94N30P3	300	94	0.036	5510	102	-	250	1040	0.12	TO-268
IXFQ94N30P3	300	94	0.036	5510	102	-	250	1040	0.12	TO-3P
IXFL210N30P3	300	108	0.016	16200	268	-	250	520	0.24	ISOPLUS264
IXFN140N30P	300	110	0.024	14800	185	-	200	700	0.18	SOT-227B
IXFK120N30P3	300	120	0.027	8630	150	-	250	1130	0.11	TO-264
IXFX120N30P3	300	120	0.027	8630	150	-	250	1130	0.11	PLUS247
IXFN170N30P	300	138	0.018	20000	258	-	200	890	0.14	SOT-227
IXFX140N30P	300	140	0.024	14800	185	-	200	1040	0.12	PLUS247
IXFK150N30P3	300	150	0.019	12100	197	-	250	1300	0.096	TO-264
IXFX150N30P3	300	150	0.019	12100	197	-	250	1300	0.096	PLUS247
IXFB170N30P	300	170	0.018	20000	258	-	200	1250	0.1	PLUS264
IXFN210N30P3	300	192	0.0145	16200	268	-	250	1500	0.083	SOT-227
IXFB210N30P3	300	210	0.0145	16200	268	-	250	1890	0.066	PLUS264
IXFP3N50PM	500	2.7	2	409	9.3	-	200	36	3.5	TO-220 Overmolded
IXFP8N50PM	500	4.4	0.8	1050	20	-	200	42	3	TO-220 Overmolded
IXFY5N50P3	500	5	1.65	370	6.9	-	250	114	1.1	TO-252
IXFP5N50P3	500	5	1.65	370	6.9	-	250	114	1.1	TO-220
IXFA5N50P3	500	5	1.65	370	6.9	-	250	114	1.1	TO-263
IXFP12N50PM	500	6	0.5	1830	29	-	300	50	2.5	TO-220 Overmolded
IXFP8N50P3	500	8	0.8	705	13	-	250	180	0.69	TO-220
IXFP20N50P3M	500	8	0.3	1800	36	-	250	58	2.15	TO-220 Overmolded
IXFA8N50P3	500	8	0.8	705	13	-	250	180	0.69	TO-263
IXFA12N50P	500	12	0.5	1830	29	-	200	200	0.62	TO-263
IXFP12N50P	500	12	0.5	1830	29	-	200	200	0.62	TO-220
IXFH13N50	500	13	0.4	2800	110	-	250	179	0.7	TO-247
IXFA16N50P3	500	16	0.36	1515	29	-	250	330	0.38	TO-263
IXFP16N50P	500	16	0.4	2480	43	-	200	300	0.42	TO-220
IXFH16N50P3	500	16	0.36	1515	29	-	250	330	0.38	TO-247
IXFP16N50P3	500	16	0.36	1515	29	-	250	330	0.38	TO-220
IXFA16N50P	500	16	0.4	2480	43	-	200	300	0.42	TO-263
IXFH16N50P	500	16	0.4	2480	43	-	200	300	0.42	TO-247
IXFR36N50P	500	19	0.19	5500	93	-	200	156	0.75	ISOPLUS247?
IXFA20N50P3	500	20	0.3	1800	36	-	250	380	0.36	TO-263
IXFQ20N50P3	500	20	0.3	1800	36	-	250	380	0.36	TO-3P
IXFH20N50P3	500	20	0.3	1800	36	-	250	380	0.36	TO-247
IXFP20N50P3	500	20	0.3	1800	36	-	250	380	0.36	TO-220
IXFQ24N50P2	500	24	0.27	2890	48	-	200	480	0.26	TO-3P
IXFR44N50Q3	500	25	0.154	4800	93	-	250	300	0.41	ISOPLUS247
IXFQ26N50P3	500	26	0.25	2220	42	-	250	500	0.25	TO-3P
IXFH26N50P3	500	26	0.25	2220	42	-	250	500	0.25	TO-247
IXFP26N50P3	500	26	0.25	2220	42	-	250	500	0.25	TO-220
IXFA26N50P3	500	26	0.25	2220	42	-	250	500	0.25	TO-263
IXFH26N50P	500	26	0.23	3600	60	-	200	400	0.31	TO-247
IXFH30N50P	500	30	0.2	4150	70	-	200	460	0.27	TO-247
IXFT30N50Q3	500	30	0.2	3200	62	-	250	690	0.18	TO-268
IXFH30N50Q3	500	30	0.2	3200	62	-	250	690	0.18	TO-247
IXFT30N50P	500	30	0.2	4150	70	-	200	460	0.27	TO-268
IXFH34N50P3	500	34	0.18	3260	60	-	250	695	0.18	TO-247
IXFT36N50P	500	36	0.17	5500	93	-	200	540	0.23	TO-268
IXFH36N50P	500	36	0.17	5500	93	-	200	540	0.23	TO-247
IXFR64N50P	500	37	0.095	9700	150	-	200	300	0.42	ISOPLUS247
IXFT42N50P2	500	42	0.145	5300	92	-	250	830	0.15	TO-268
IXFH42N50P2	500	42	0.145	5300	92	-	250	830	0.15	TO-247
IXFT44N50P	500	44	0.14	5440	98	-	200	650	0.19	TO-268
IXFT44N50Q3	500	44	0.14	4800	93	-	250	830	0.15	TO-268
IXFH44N50Q3	500	44	0.14	4800	93	-	250	830	0.15	TO-247
IXFR64N50Q3	500	45	0.094	6950	145	-	250	500	0.25	ISOPLUS247
IXFR80N50P	500	45	0.072	12700	197	-	200	360	0.35	ISOPLUS247?
IXFR80N50Q3	500	50	0.072	10000	200	-	250	570	0.22	ISOPLUS247
IXFN50N50	500	50	0.1	9400	330	-	250	595	0.21	SOT-227B
IXFQ50N50P3	500	50	0.125	4335	85	-	250	960	0.13	TO-3P
IXFT50N50P3	500	50	0.125	4335	85	-	250	960	0.13	TO-268
IXFN64N50P	500	50	0.085	9700	150	-	200	625	0.2	SOT-227
IXFH52N50P2	500	52	0.12	6800	113	-	250	960	0.13	TO-247
IXFT52N50P2	500	52	0.12	6800	113	-	250	960	0.13	TO-268
IXFT60N50P3	500	60	0.11	6250	96	-	250	1040	0.12	TO-268
IXFQ60N50P3	500	60	0.11	6250	96	-	250	1040	0.12	TO-3P
IXFH60N50P3	500	60	0.11	6250	96	-	250	1040	0.12	TO-247
IXFL132N50P3	500	63	0.043	18600	250	-	250	520	0.24	ISOPLUS264?
IXFN80N50Q3	500	63	0.065	10000	200	-	250	780	0.16	SOT-227
IXFX64N50P	500	64	0.085	9700	150	-	200	830	0.15	PLUS247
IXFK64N50P	500	64	0.085	9700	150	-	200	830	0.15	TO-264
IXFK64N50Q3	500	64	0.085	6950	145	-	250	1000	0.125	TO-264
IXFX64N50Q3	500	64	0.085	6950	145	-	250	1000	0.125	PLUS247
IXFN80N50P	500	66	0.065	12700	195	-	200	700	0.18	SOT-227B
IXFX66N50Q2	500	66	0.08	9125	200	-	250	735	0.17	PLUS247
IXFN94N50P2	500	68	0.055	13700	220	-	250	780	0.16	SOT-227
IXFL100N50P	500	70	0.052	20000	240	-	200	625	0.2	ISOPLUS264
IXFK78N50P3	500	78	0.068	9900	147	-	250	1130	0.11	TO-264
IXFX78N50P3	500	78	0.068	9900	147	-	250	1130	0.11	PLUS247
IXFX80N50Q3	500	80	0.065	10000	200	-	250	1250	0.1	PLUS247
IXFB80N50Q2	500	80	0.06	15000	250	-	250	960	0.13	PLUS264
IXFX80N50P	500	80	0.065	12700	197	-	200	1040	0.12	PLUS247
IXFN80N50	500	80	0.055	9890	380	-	250	694	0.18	SOT-227B
IXFF80N50Q2	500	80	0.066	10500	260	-	250	380	0.33	ISOPLUS i4-PAC? (3 - Lead)
IXFK80N50Q3	500	80	0.065	10000	200	-	250	1250	0.1	TO-264
IXFK80N50P	500	80	0.065	12700	197	-	200	1040	0.12	TO-264
IXFN100N50Q3	500	82	0.049	13800	255	-	250	960	0.13	SOT-227
IXFN100N50P	500	90	0.049	20000	240	-	200	1040	0.12	SOT-227B
IXFX94N50P2	500	94	0.055	14200	228	-	250	1300	0.096	PLUS247
IXFX98N50P3	500	98	0.05	12900	200	-	250	1300	0.096	PLUS247
IXFB100N50Q3	500	100	0.049	13800	255	-	250	1560	0.08	PLUS264
IXFB100N50P	500	100	0.049	20000	240	-	200	1890	0.066	PLUS264
IXFN132N50P3	500	112	0.039	18600	250	-	250	1500	0.083	SOT-227
IXFB120N50P2	500	120	0.043	19000	300	-	300	1890	0.066	PLUS264
IXFB132N50P3	500	132	0.039	18600	267	-	250	1890	0.066	PLUS264
IXFY4N60P3	600	4	2.4	365	6.9	-	250	114	1.1	TO-252
IXFA4N60P3	600	4	2.4	365	6.9	-	250	114	1.1	TO-263
IXFP4N60P3	600	4	2.4	365	6.9	-	250	114	1.1	TO-220
IXFP7N60P3	600	7	1.15	705	13.3	-	250	180	0.69	TO-220
IXFA7N60P3	600	7	1.15	705	13.3	-	250	180	0.69	TO-263
IXFC14N60P	600	8	0.63	2500	36	-	200	125	1	ISOPLUS220?
IXFP10N60P	600	10	0.74	1720	32	120	200	200	0.62	TO-220
IXFA10N60P	600	10	0.74	1720	32	120	200	200	0.62	TO-263
IXFC22N60P	600	12	0.36	4000	58	-	200	130	0.95	ISOPLUS220?
IXFA14N60P	600	14	0.55	2500	36	-	200	300	0.42	TO-263
IXFH14N60P	600	14	0.55	2500	36	-	200	300	0.42	TO-247
IXFA14N60P3	600	14	0.54	1480	25	-	250	327	0.38	TO-263
IXFH14N60P3	600	14	0.54	1480	25	-	250	327	0.38	TO-247
IXFP14N60P	600	14	0.55	2500	36	-	200	300	0.42	TO-220
IXFP14N60P3	600	14	0.54	1480	25	-	250	327	0.38	TO-220
IXFR30N60P	600	15	0.25	3820	85	-	200	166	0.75	ISOPLUS247?
IXFH15N60	600	15	0.5	4500	151	-	250	298	0.42	TO-247
IXFM15N60	600	15	0.5	4500	151	-	250	298	0.42	TO-204
IXFC30N60P	600	15	0.25	3820	85	-	200	166	0.75	ISOPLUS220?
IXFA16N60P3	600	16	0.47	1830	36	-	250	347	0.36	TO-263
IXFH16N60P3	600	16	0.47	1830	36	-	250	347	0.36	TO-247
IXFP16N60P3	600	16	0.47	1830	36	-	250	347	0.36	TO-220
IXFH18N60P	600	18	0.4	2500	50	-	200	360	0.35	TO-247
IXFV18N60P	600	18	0.4	2500	50	-	200	360	0.35	PLUS-200
IXFV18N60PS	600	18	0.4	2500	50	-	200	360	0.35	PLUS-220 SMD
IXFH20N60Q	600	20	0.35	3700	95	-	250	298	0.42	TO-247
IXFR36N60P	600	20	0.2	5800	102	-	200	208	0.6	ISOPLUS247?
IXFH20N60	600	20	0.35	4500	151	-	250	298	0.42	TO-247
IXFM20N60	600	20	0.35	4500	151	-	250	298	0.42	TO-204
IXFT20N60Q	600	20	0.35	3700	95	-	250	298	0.42	TO-268
IXFP22N60P3	600	22	0.39	2600	38	-	250	500	0.25	TO-220
IXFV22N60PS	600	22	0.35	3600	58	-	200	400	0.31	PLUS-220 SMD
IXFV22N60P	600	22	0.35	3600	58	-	200	400	0.31	PLUS-200
IXFH22N60P	600	22	0.35	3600	58	-	200	400	0.31	TO-247
IXFA22N60P3	600	22	0.39	2600	38	-	250	500	0.25	TO-263
IXFH22N60P3	600	22	0.39	2600	38	-	250	500	0.25	TO-247
IXFQ22N60P3	600	22	0.39	2600	38	-	250	500	0.25	TO-3P
IXFR26N60Q	600	23	0.25	5100	150	-	250	313	0.4	ISOPLUS247?
IXFH23N60Q	600	23	0.32	3300	90	-	250	400	0.31	TO-247
IXFV26N60PS	600	26	0.27	4150	72	-	200	460	0.27	PLUS-220 SMD
IXFT26N60P	600	26	0.27	4150	72	-	200	460	0.27	TO-268
IXFV26N60P	600	26	0.27	4150	72	-	200	460	0.27	PLUS-200
IXFH26N60P	600	26	0.27	4150	72	-	200	460	0.27	TO-247
IXFT26N60Q	600	28	0.25	5100	150	-	250	357	0.35	TO-268
IXFK26N60Q	600	28	0.25	5100	150	-	250	357	0.35	TO-264
IXFQ28N60P3	600	28	0.26	3560	50	-	250	695	0.18	TO-3P
IXFX26N60Q	600	28	0.25	5100	150	-	250	357	0.35	PLUS247
IXFH26N60Q	600	28	0.25	5100	150	-	250	357	0.35	TO-247
IXFH30N60P	600	30	0.24	4000	82	-	200	500	0.25	TO-247
IXFT30N60P	600	30	0.24	4000	82	-	200	500	0.25	TO-268
IXFV30N60PS	600	30	0.24	4000	82	-	200	500	0.25	PLUS-220 SMD
IXFH30N60Q	600	30	0.23	4700	124	-	250	500	0.25	TO-247
IXFV30N60P	600	30	0.24	4000	82	-	200	500	0.25	PLUS-200
IXFR48N60P	600	32	0.15	8860	150	-	200	300	0.42	ISOPLUS247?
IXFR48N60Q3	600	32	0.154	7020	140	-	300	500	0.25	ISOPLUS247
IXFK32N60	600	32	0.25	9000	325	-	250	500	0.25	TO-264
IXFN32N60	600	32	0.25	9000	325	-	250	521	0.24	SOT-227B
IXFT36N60P	600	36	0.19	5800	102	-	200	650	0.19	TO-268
IXFK36N60	600	36	0.18	9000	325	-	250	500	0.25	TO-264
IXFK36N60P	600	36	0.19	5800	102	-	200	650	0.19	TO-264
IXFN36N60	600	36	0.18	9000	325	-	250	521	0.24	SOT-227B
IXFR64N60P	600	36	0.105	12000	200	-	200	320	0.39	ISOPLUS247?
IXFH36N60P	600	36	0.19	5800	102	-	200	650	0.19	TO-247
IXFL70N60Q2	600	37	0.092	12000	265	-	250	360	0.35	ISOPLUS264
IXFR44N60	600	38	0.13	8900	330	-	250	417	0.3	ISOPLUS247?
IXFN48N60P	600	40	0.14	8860	150	-	200	625	0.2	SOT-227B
IXFE44N60	600	41	0.13	8900	330	-	250	500	0.25	ISOPLUS227?
IXFR64N60Q3	600	42	0.104	9930	190	-	300	568	0.22	ISOPLUS247
IXFH42N60P3	600	42	0.185	5150	78	-	250	830	0.15	TO-247
IXFL44N60	600	44	0.13	8900	330	-	250	568	0.22	ISOPLUS264
IXFK44N60	600	44	0.13	8900	330	-	250	568	0.22	TO-264
IXFX44N60	600	44	0.13	8900	330	-	250	568	0.22	PLUS247
IXFN44N60	600	44	0.13	8900	330	-	250	568	0.22	SOT-227B
IXFK48N60P	600	48	0.135	8860	150	-	200	830	0.15	TO-264
IXFK48N60Q3	600	48	0.14	7020	140	-	300	1000	0.125	TO-264
IXFX48N60P	600	48	0.135	8860	150	-	200	830	0.15	PLUS247
IXFR80N60P3	600	48	0.085	13100	190	-	250	540	0.23	ISOPLUS247
IXFX48N60Q3	600	48	0.14	7020	140	-	300	1000	0.125	PLUS247
IXFN64N60P	600	50	0.096	12000	200	-	200	700	0.18	SOT-227B
IXFH50N60P3	600	50	0.16	6300	94	-	250	1040	0.12	TO-247
IXFT50N60P3	600	50	0.16	6300	94	-	250	1040	0.12	TO-268
IXFQ50N60P3	600	50	0.16	6300	94	-	250	1040	0.12	TO-3P
IXFK52N60Q2	600	52	0.115	6800	198	-	250	735	0.17	TO-264
IXFX52N60Q2	600	52	0.115	6800	198	-	250	735	0.17	PLUS247
IXFL82N60P	600	54	0.08	23000	240	-	200	625	0.2	ISOPLUS264
IXFN60N60	600	60	0.08	15000	380	-	250	694	0.18	SOT-227B
IXFL60N60	600	60	0.08	15000	380	-	250	694	0.18	ISOPLUS264
IXFK64N60P	600	64	0.096	12000	200	-	200	1040	0.12	TO-264
IXFX64N60Q3	600	64	0.095	9930	190	-	300	1250	0.1	PLUS247
IXFK64N60P3	600	64	0.1	9900	145	-	250	1130	0.11	TO-264
IXFK64N60Q3	600	64	0.095	9930	190	-	300	1250	0.1	TO-264
IXFX64N60P3	600	64	0.1	9900	145	-	250	1130	0.11	PLUS247
IXFX64N60P	600	64	0.096	12000	200	-	200	1040	0.12	PLUS247
IXFN82N60Q3	600	66	0.075	13500	275	-	300	960	0.13	SOT-227
IXFN80N60P3	600	66	0.077	13100	190	-	250	960	0.13	SOT-227
IXFB70N60Q2	600	70	0.088	12000	265	-	250	890	0.14	PLUS264
IXFN70N60Q2	600	70	0.088	12000	265	-	250	890	0.14	SOT-227B
IXFN82N60P	600	72	0.075	23000	240	-	200	1040	0.12	SOT-227B
IXFX80N60P3	600	80	0.077	13100	190	-	250	1300	0.096	PLUS247
IXFK80N60P3	600	80	0.077	13100	190	-	250	1300	0.096	TO-264
IXFB82N60P	600	82	0.075	23000	240	-	200	1250	0.1	PLUS264
IXFB82N60Q3	600	82	0.075	13500	275	-	300	1560	0.08	PLUS264
IXFN110N60P3	600	90	0.056	18000	254	-	250	1500	0.083	SOT-227
IXFB110N60P3	600	110	0.056	18000	254	-	250	1890	0.066	PLUS264
IXFP7N80PM	800	3.5	1.44	1890	32	-	250	50	2.5	TO-220 Overmolded
IXFA3N80	800	3.6	3.6	685	24	-	250	100	1.25	TO-263
IXFP3N80	800	3.6	3.6	685	24	-	250	100	1.25	TO-220
IXFC10N80P	800	5	1.2	2300	40	-	250	100	1.25	ISOPLUS220?
IXFA7N80P	800	7	1.44	1800	32	-	250	200	0.62	TO-263
IXFM7N80	800	7	1.4	2800	110	-	250	179	0.7	TO-204
IXFH7N80	800	7	1.4	2800	110	-	250	179	0.7	TO-247
IXFC12N80P	800	7	0.93	2800	51	-	250	120	1.05	ISOPLUS220?
IXFP7N80P	800	7	1.44	1800	32	-	250	200	0.62	TO-220
IXFH8N80	800	8	1.1	2600	85	-	250	179	0.7	TO-247
IXFC14N80P	800	8	0.77	3900	61	-	250	130	0.95	ISOPLUS220?
IXFH9N80	800	9	0.9	2600	85	-	250	179	0.7	TO-247
IXFC16N80P	800	9	0.65	4000	70	-	250	138	0.9	ISOPLUS220?
IXFH9N80Q	800	9	1.1	2200	56	-	250	179	0.7	TO-247
IXFH10N80P	800	10	1.1	2050	40	-	250	300	0.42	TO-247
IXFC20N80P	800	10	0.57	4685	86	-	250	160	0.8	ISOPLUS220?
IXFQ10N80P	800	10	1.1	2050	40	-	250	300	0.42	TO-3P
IXFP10N80P	800	10	1.1	2050	40	-	250	300	0.42	TO-220
IXFA10N80P	800	10	1.1	2050	40	-	250	300	0.42	TO-263
IXFR20N80P	800	10	0.57	4685	86	-	250	160	0.8	ISOPLUS247?
IXFM11N80	800	11	0.95	4200	128	-	250	298	0.42	TO-204
IXFH11N80	800	11	0.95	4200	128	-	250	298	0.42	TO-247
IXFV12N80P	800	12	0.85	2800	51	-	250	360	0.35	PLUS-200
IXFH12N80P	800	12	0.85	2800	51	-	250	360	0.35	TO-247
IXFV12N80PS	800	12	0.85	2800	51	-	250	360	0.35	PLUS-220 SMD
IXFQ12N80P	800	12	0.85	2800	51	-	250	360	0.35	TO-3P
IXFR15N80Q	800	13	0.6	4300	90	-	250	250	0.5	ISOPLUS247?
IXFT13N80Q	800	13	0.7	3250	90	-	250	298	0.42	TO-268
IXFR24N80P	800	13	0.42	7200	105	-	250	208	0.6	ISOPLUS247?
IXFH13N80	800	13	0.8	4200	128	-	250	298	0.42	TO-247
IXFM13N80	800	13	0.8	4200	128	-	250	298	0.42	TO-204
IXFH13N80Q	800	13	0.7	3250	90	-	250	298	0.42	TO-247
IXFQ14N80P	800	14	0.72	3900	61	-	250	400	0.31	TO-3P
IXFH14N80P	800	14	0.72	3900	61	-	250	400	0.31	TO-247
IXFV14N80PS	800	14	0.72	3900	61	-	250	400	0.31	PLUS-220 SMD
IXFT14N80P	800	14	0.72	3900	61	-	250	400	0.31	TO-268
IXFV14N80P	800	14	0.72	3900	61	-	250	400	0.31	PLUS-200
IXFH14N80	800	14	0.7	3965	150	-	250	298	0.42	TO-247
IXFC15N80Q	800	15	0.6	4300	90	-	250	231	0.54	ISOPLUS220?
IXFH15N80	800	15	0.6	3965	150	-	250	298	0.42	TO-247
IXFH15N80Q	800	15	0.6	4300	90	-	250	298	0.42	TO-247
IXFT15N80Q	800	15	0.6	4300	90	-	250	298	0.42	TO-268
IXFV16N80P	800	16	0.6	4000	70	-	250	460	0.27	PLUS-200
IXFT16N80P	800	16	0.6	4000	70	-	250	460	0.27	TO-268
IXFH16N80P	800	16	0.6	4000	70	-	250	460	0.27	TO-247
IXFV16N80PS	800	16	0.6	4000	70	-	250	460	0.27	PLUS-220 SMD
IXFH17N80Q	800	17	0.6	4300	88	-	250	400	0.31	TO-247
IXFH20N80P	800	20	0.52	4685	86	-	250	500	0.25	TO-247
IXFV20N80PS	800	20	0.52	4685	86	-	250	500	0.25	PLUS-220 SMD
IXFT20N80Q	800	20	0.42	5100	150	-	250	357	0.35	TO-268
IXFH20N80Q	800	20	0.42	5100	150	-	250	357	0.35	TO-247
IXFV20N80P	800	20	0.52	4685	86	-	250	500	0.25	PLUS-200
IXFT20N80P	800	20	0.52	4685	86	-	250	500	0.25	TO-268
IXFK20N80Q	800	20	0.42	5100	150	-	250	357	0.35	TO-264
IXFR32N80P	800	20	0.29	8800	150	-	250	300	0.42	ISOPLUS247?
IXFH23N80Q	800	23	0.42	5100	120	-	250	500	0.25	TO-247
IXFK24N80P	800	24	0.4	7200	105	-	250	650	0.19	TO-264
IXFT24N80P	800	24	0.4	5800	100	-	250	650	0.19	TO-268
IXFR32N80Q3	800	24	0.3	6940	140	-	300	500	0.25	ISOPLUS247
IXFH24N80P	800	24	0.4	5800	100	-	250	650	0.19	TO-247
IXFR44N80P	800	26	0.19	12000	200	-	250	360	0.35	ISOPLUS247?
IXFK27N80Q	800	27	0.32	7600	170	-	250	481	0.26	TO-264
IXFX27N80Q	800	27	0.32	7600	170	-	250	481	0.26	PLUS247
IXFN27N80	800	27	0.32	8400	350	-	250	520	0.24	SOT-227B
IXFN27N80Q	800	27	0.32	7600	170	-	250	521	0.24	SOT-227B
IXFK27N80	800	27	0.32	8400	350	-	250	500	0.25	TO-264
IXFR34N80	800	28	0.265	7500	270	-	250	416	0.3	ISOPLUS247?
IXFR38N80Q2	800	28	0.24	9500	190	-	250	500	0.25	ISOPLUS247?
IXFN32N80P	800	29	0.27	8820	150	-	250	625	0.2	SOT-227B
IXFK32N80Q3	800	32	0.27	6940	140	-	300	1000	0.125	TO-264
IXFX32N80P	800	32	0.27	8800	150	-	250	830	0.15	PLUS247
IXFK32N80P	800	32	0.27	8800	150	-	250	830	0.15	TO-264
IXFX32N80Q3	800	32	0.27	6940	140	-	300	1000	0.125	PLUS247
IXFK34N80	800	34	0.24	7500	270	-	250	568	0.22	TO-264
IXFN34N80	800	34	0.24	7500	270	-	250	568	0.22	SOT-227B
IXFX34N80	800	34	0.24	7500	270	-	250	568	0.22	PLUS247
IXFN44N80P	800	36	0.19	12000	200	-	250	1200	0.12	SOT-227B
IXFN44N80Q3	800	37	0.19	10950	185	-	300	780	0.16	SOT-227B
IXFK38N80Q2	800	38	0.22	9500	190	-	250	735	0.17	TO-264
IXFN38N80Q2	800	38	0.22	9500	190	-	250	735	0.17	SOT-227B
IXFX38N80Q2	800	38	0.22	9500	190	-	250	735	0.17	PLUS247
IXFL60N80P	800	40	0.15	18000	250	-	250	625	0.2	ISOPLUS264
IXFX44N80Q3	800	44	0.19	10950	185	-	300	1250	0.1	PLUS247
IXFL44N80	800	44	0.165	10000	380	-	250	694	0.18	ISOPLUS264
IXFK44N80Q3	800	44	0.19	10950	185	-	300	1250	0.1	TO-264
IXFN44N80	800	44	0.165	10000	380	-	250	694	0.18	SOT-227B
IXFX44N80P	800	44	0.19	12000	198	-	250	1200	0.12	PLUS247
IXFN62N80Q3	800	49	0.14	13600	270	-	300	960	0.13	SOT-227B
IXFN50N80Q2	800	50	0.16	13500	260	-	300	1135	0.11	SOT-227
IXFB50N80Q2	800	50	0.16	7200	260	-	300	1135	0.11	PLUS264
IXFN60N80P	800	53	0.14	18000	250	-	250	1040	0.12	SOT-227B
IXFB60N80P	800	60	0.14	18000	250	-	250	1250	0.1	PLUS264
IXFB62N80Q3	800	62	0.14	13600	270	-	300	1560	0.08	PLUS264
IXFM6N90	900	6	1.8	2600	88	-	250	179	0.7	TO-204
IXFH6N90	900	6	1.8	2600	88	-	250	179	0.7	TO-247
IXFT7N90Q	900	7	1.5	2200	56	-	250	180	0.7	TO-268
IXFH7N90Q	900	7	1.5	2200	56	-	250	180	0.7	TO-247
IXFM10N90	900	10	1.1	4200	123	-	250	298	0.42	TO-204
IXFH10N90	900	10	1.1	4200	123	-	250	298	0.42	TO-247
IXFR18N90P	900	10.5	0.66	5230	97	-	300	200	0.62	ISOPLUS247
IXFH12N90Q	900	12	0.9	2900	90	-	200	298	0.42	TO-247
IXFV12N90PS	900	12	1	3080	56	-	300	380	0.33	PLUS-220 SMD
IXFH12N90	900	12	0.9	4200	123	-	250	298	0.42	TO-247
IXFV12N90P	900	12	1	3080	56	-	300	380	0.33	PLUS-200
IXFM12N90Q	900	12	0.9	2900	90	-	250	298	0.42	TO-204
IXFT12N90Q	900	12	0.9	2900	90	-	200	298	0.42	TO-268
IXFM12N90	900	12	0.9	4200	123	-	250	298	0.42	TO-204
IXFH13N90	900	13	0.8	4200	123	-	250	298	0.42	TO-247
IXFR24N90P	900	13	0.46	7200	130	-	300	230	0.54	ISOPLUS247
IXFH16N90Q	900	16	0.65	4000	133	-	250	357	0.35	TO-247
IXFT16N90Q	900	16	0.65	4000	133	-	250	357	0.35	TO-268
IXFK16N90Q	900	16	0.65	4000	133	-	250	357	0.35	TO-264
IXFH18N90P	900	18	0.6	5230	97	-	300	540	0.23	TO-247
IXFV18N90P	900	18	0.6	5230	97	-	300	540	0.23	PLUS-200
IXFT18N90P	900	18	0.6	5230	97	-	300	540	0.23	TO-268
IXFV18N90PS	900	18	0.6	5230	97	-	300	540	0.23	PLUS-220 SMD
IXFR40N90P	900	21	0.25	14000	230	-	300	300	0.42	ISOPLUS247
IXFK24N90Q	900	24	0.45	5900	170	-	250	481	0.26	TO-264
IXFT24N90P	900	24	0.42	7200	130	-	300	660	0.19	TO-268
IXFH24N90P	900	24	0.42	7200	130	-	300	660	0.19	TO-247
IXFX24N90Q	900	24	0.45	5900	170	-	250	481	0.26	PLUS247
IXFN25N90	900	25	0.33	8700	240	-	250	600	0.21	SOT-227
IXFX25N90	900	25	0.33	8700	260	-	250	560	0.22	PLUS247
IXFK25N90	900	25	0.33	8700	260	-	250	560	0.22	TO-264
IXFN26N90	900	26	0.3	8700	240	-	250	600	0.21	SOT-227
IXFK26N90	900	26	0.3	8700	260	-	250	560	0.22	TO-264
IXFX26N90	900	26	0.30.	8700	260	-	250	560	0.22	PLUS247
IXFK32N90P	900	32	0.3	10600	215	-	300	960	0.13	TO-264
IXFX32N90P	900	32	0.3	10600	215	-	300	960	0.13	PLUS247
IXFN40N90P	900	33	0.23	14000	230	-	300	695	0.18	SOT-227
IXFE39N90	900	34	0.22	13400	375	-	250	580	0.22	ISOPLUS227?
IXFL39N90	900	39	0.22	9200	390	-	250	694	0.18	ISOPLUS264
IXFN39N90	900	39	0.22	9200	390	-	250	694	0.18	SOT-227B
IXFK40N90P	900	40	0.23	14000	230	-	300	960	0.13	TO-264
IXFX40N90P	900	40	0.23	14000	230	-	300	960	0.13	PLUS247
IXFN52N90P	900	43	0.16	19000	308	-	300	890	0.14	SOT-227
IXFB52N90P	900	52	0.16	19000	308	-	300	1250	0.1	PLUS264
IXFN56N90P	900	56	0.145	23000	375	-	300	1000	0.125	SOT-227
IXFR24N90Q	900	-	0.4	5900	170	-	250	-	-	ISOPLUS247?
IXFP05N100M	1000	0.7	17	260	7.8	-	300	25	5	OVERMOLDED TO-220
IXFP4N100PM	1000	2.1	3.3	1456	26	-	300	40	3.1	OVERMOLDED
IXFP4N100QM	1000	2.2	3	1185	43.5	-	250	46	2.7	TO-220 Overmolded
IXFP5N100PM	1000	2.3	2.8	1830	33.4	-	200	42	3	OVERMOLDED
IXFR4N100Q	1000	3.5	3	1050	39	-	200	80	1.57	ISOPLUS247?
IXFP4N100P	1000	4	3.3	1456	26	-	300	150	0.83	TO-220
IXFH4N100Q	1000	4	3	1050	39	-	250	156	0.8	TO-247
IXFP4N100Q	1000	4	3	1050	39	-	250	156	0.8	TO-220
IXFT4N100Q	1000	4	3	1050	39	-	250	156	0.8	TO-268
IXFA4N100P	1000	4	3.3	1456	26	-	300	150	0.83	TO-263
IXFA4N100Q	1000	4	3	1050	39	-	250	156	0.8	TO-263
IXFA5N100P	1000	5	2.8	1830	33.4	-	200	250	0.5	TO-263
IXFP5N100P	1000	5	2.8	1830	33.4	-	200	250	0.5	TO-220
IXFH5N100P	1000	5	2.8	1830	33.4	-	200	250	0.5	TO-247
IXFM6N100	1000	6	2	2600	88	-	250	179	0.7	TO-204
IXFH6N100Q	1000	6	2	2200	48	-	250	66	1.9	TO-247
IXFH6N100	1000	6	2	2600	88	-	250	179	0.7	TO-247
IXFT6N100Q	1000	6	2	2200	48	-	250	66	1.9	TO-268
IXFP7N100P	1000	7	1.9	2590	47	-	300	300	0.42	TO-220
IXFH7N100P	1000	7	1.9	2590	47	-	300	300	0.42	TO-247
IXFA7N100P	1000	7	1.9	2590	47	-	300	300	0.42	TO-263
IXFR14N100Q2	1000	9.5	1.1	2800	83	-	300	200	0.62	ISOPLUS247
IXFM10N100	1000	10	1.2	4000	122	-	250	298	0.42	TO-204
IXFT10N100	1000	10	1.2	4000	122	-	250	298	0.42	TO-268
IXFH10N100P	1000	10	1.4	3030	56	-	300	380	0.33	TO-247
IXFH10N100	1000	10	1.2	4000	122	-	250	298	0.42	TO-247
IXFR15N100Q3	1000	10	1.2	3250	64	-	250	400	0.31	ISOPLUS247
IXFR20N100P	1000	11	0.64	7300	126	-	300	230	0.54	ISOPLUS247
IXFT12N100QHV	1000	12	1.05	3050	95	200	250	445	0.28	TO-268-2L
IXFT12N100	1000	12	1.05	4000	122	-	250	298	0.42	TO-268
IXFT13N100	1000	12	1.05	4000	122	-	250	298	0.42	TO-268
IXFH12N100P	1000	12	1.05	4080	80	-	300	463	0.27	TO-247
IXFR12N100Q	1000	12	1.05	2900	90	-	200	250	0.5	ISOPLUS247?
IXFV12N100PS	1000	12	1.05	4080	80	-	300	463	0.27	PLUS-220 SMD
IXFT12N100Q	1000	12	1.05	2900	90	-	200	300	0.42	TO-268
IXFH12N100	1000	12	1.05	4000	122	-	250	298	0.42	TO-247
IXFV12N100P	1000	12	1.05	4080	80	-	300	463	0.27	PLUS-200
IXFM12N100	1000	12	1.05	4000	122	-	250	298	0.42	TO-204
IXFH12N100Q	1000	12	1.05	2900	90	-	200	300	0.42	TO-247
IXFH13N100	1000	12.5	0.9	4000	122	-	250	300	0.42	TO-247
IXFH14N100	1000	14	0.75	4500	220	-	200	357	0.35	TO-247
IXFX14N100	1000	14	0.75	4500	220	-	200	357	0.35	PLUS247
IXFH14N100Q2	1000	14	0.95	2800	83	-	300	500	0.25	TO-247
IXFT14N100	1000	14	0.75	4500	220	-	200	357	0.35	TO-268
IXFV15N100PS	1000	15	0.76	5140	97	-	300	543	0.23	PLUS-220 SMD
IXFH15N100Q3	1000	15	1.05	3250	64	-	250	690	0.18	TO-247
IXFH15N100P	1000	15	0.76	5140	97	-	300	543	0.23	TO-247
IXFT15N100	1000	15	0.7	4500	220	-	200	357	0.35	TO-268
IXFV15N100P	1000	15	0.76	5140	97	-	300	543	0.23	PLUS-200
IXFK15N100Q	1000	15	0.7	4500	130	-	250	357	0.35	TO-264
IXFT15N100Q	1000	15	0.7	4500	130	-	250	357	0.35	TO-268
IXFH15N100	1000	15	0.7	4500	220	-	200	357	0.35	TO-247
IXFT15N100Q3	1000	15	1.05	3250	64	-	250	690	0.18	TO-268
IXFR26N100P	1000	15	0.43	11900	197	-	300	290	0.43	ISOPLUS247
IXFX15N100	1000	15	0.7	4500	220	-	200	357	0.35	PLUS247
IXFH15N100Q	1000	15	0.7	4500	130	-	250	357	0.35	TO-247
IXFT18N100Q3	1000	18	0.66	4890	90	-	3	830	0.15	T0-268
IXFR21N100Q	1000	18	0.5	5900	170	-	250	417	0.3	ISOPLUS247?
IXFR24N100Q3	1000	18	0.49	7200	140	-	300	500	0.25	ISOPLUS247
IXFR32N100P	1000	18	0.34	14200	225	-	300	320	0.39	ISOPLUS247
IXFH18N100Q3	1000	18	0.66	4890	90	-	300	830	0.15	TO-247
IXFT20N100P	1000	20	0.57	7300	126	-	300	660	0.19	TO-268
IXFH20N100P	1000	20	0.57	7300	126	-	300	660	0.19	TO-247
IXFN21N100Q	1000	21	0.5	5900	170	-	250	521	0.24	SOT-227B
IXFX21N100Q	1000	21	0.5	5900	170	-	250	481	0.26	PLUS247
IXFE23N100	1000	21	0.43	7000	250	-	250	500	0.25	ISOPLUS227?
IXFK21N100Q	1000	21	0.5	5900	170	-	250	481	0.26	TO-264
IXFR24N100	1000	22	0.39	8700	267	-	250	416	0.3	ISOPLUS247?
IXFL44N100P	1000	22	0.24	19000	305	-	300	357	0.35	ISOPLUS264
IXFE24N100	1000	22	0.39	7000	250	-	250	500	0.25	SOT-227?
IXFR32N100Q3	1000	23	0.35	10900	195	-	300	570	0.22	ISOPLUS247
IXFN23N100	1000	23	0.43	7000	250	-	250	595	0.21	SOT-227B
IXFN26N100P	1000	23	0.39	11900	197	-	300	595	0.21	SOT-227B
IXFK24N100Q3	1000	24	0.44	7200	140	-	300	1000	0.125	TO-264
IXFK24N100	1000	24	0.39	8700	267	-	250	560	0.22	TO-264
IXFX24N100	1000	24	0.39	8700	267	-	250	560	0.22	PLUS247
IXFX24N100Q3	1000	24	0.44	7200	140	-	300	1000	0.125	PLUS247
IXFN24N100	1000	24	0.39	8700	267	-	250	568	0.22	SOT-227B
IXFX26N100P	1000	26	0.39	11900	197	-	300	780	0.16	PLUS247
IXFK26N100P	1000	26	0.39	11900	197	-	300	780	0.16	TO-264
IXFN32N100P	1000	27	0.32	14200	225	-	300	690	0.18	SOT-227B
IXFN32N100Q3	1000	28	0.32	10900	195	-	300	780	0.16	SOT-227
IXFL38N100P	1000	29	0.23	24000	350	-	300	520	0.24	ISOPLUS i5-PAK
IXFL38N100Q2	1000	29	0.28	13500	250	-	300	380	0.33	ISOPLUS264
IXFL34N100	1000	30	0.28	9200	380	-	300	550	0.225	ISOPLUS264
IXFK30N100Q2	1000	30	0.4	9400	186	-	300	735	0.17	TO-264
IXFX30N100Q2	1000	30	0.4	9400	186	-	300	735	0.17	PLUS247
IXFK32N100P	1000	32	0.32	14200	225	-	300	960	0.13	TO-264
IXFK32N100Q3	1000	32	0.32	10900	195	-	250	1250	0.1	TO-264
IXFX32N100Q3	1000	32	0.32	10900	195	-	250	1250	0.1	PLUS247
IXFX32N100P	1000	32	0.32	14200	225	-	300	960	0.13	PLUS247
IXFN34N100	1000	34	0.28	9200	380	-	180	694	0.18	SOT-227B
IXFN36N100	1000	36	0.24	9200	380	-	180	694	0.18	SOT-227B
IXFN44N100P	1000	37	0.22	19000	305	-	300	890	0.14	SOT-227B
IXFN38N100Q2	1000	38	0.25	13500	250	-	300	890	0.14	SOT-227B
IXFN38N100P	1000	38	0.21	24000	350	-	300	1000	0.125	SOT-227B
IXFN44N100Q3	1000	38	0.22	13600	264	-	300	960	0.13	SOT-227
IXFB38N100Q2	1000	38	0.25	13500	250	-	300	890	0.14	PLUS264
IXFB44N100P	1000	44	0.22	19000	305	-	300	1250	0.1	PLUS264
IXFB44N100Q3	1000	44	0.22	13600	264	-	300	1560	0.08	PLUS264
IXFR30N110P	1100	16	0.4	13600	235	-	300	320	0.39	ISOPLUS247
IXFL40N110P	1100	21	0.28	19000	310	-	300	357	0.35	ISOPLUS264
IXFN30N110P	1100	25	0.36	13600	235	-	300	695	0.18	SOT-227B
IXFL36N110P	1100	26	0.26	23000	350	-	300	520	0.24	ISOPLUS264
IXFX30N110P	1100	30	0.36	13600	235	-	300	960	0.13	PLUS247
IXFK30N110P	1100	30	0.36	13600	235	-	300	960	0.13	TO-264
IXFN40N110P	1100	34	0.26	19000	310	-	300	890	0.14	SOT-227B
IXFN40N110Q3	1100	35	0.26	14000	300	434	-	960	0.13	SOT227
IXFN36N110P	1100	36	0.24	23000	350	-	300	1000	0.125	SOT-227B
IXFB40N110Q3	1100	40	0.26	14000	300	434	-	1560	0.08	PLUS264
IXFB40N110P	1100	40	0.26	19000	310	-	300	1250	0.1	PLUS264
IXFP3N120	1200	3	4.5	1050	39	-	300	200	0.62	TO-220
IXFA3N120	1200	3	4.5	1050	39	-	300	200	0.62	TO-263
IXFA3N120	1200	3	4.5	1050	39	-	300	200	0.62	TO-263
IXFH6N120	1200	6	2.6	1950	56	-	300	300	0.42	TO-247
IXFP6N120P	1200	6	2.75	2830	92	-	300	250	0.5	TO-220
IXFH6N120P	1200	6	2.75	2830	92	-	300	250	0.5	TO-247
IXFA6N120P	1200	6	2.75	2830	92	-	300	250	0.5	TO-263
IXFR16N120P	1200	9	1.04	6900	120	-	300	230	0.54	ISOPLUS247
IXFH12N120P	1200	12	1.35	5400	103	-	300	543	0.23	TO-247
IXFH12N120	1200	12	1.4	3400	95	-	300	500	0.25	TO-247
IXFV12N120PS	1200	12	1.35	6500	103	-	300	543	0.23	PLUS-220 SMD
IXFV12N120P	1200	12	1.35	6500	103	-	300	543	0.23	PLUS-200
IXFR20N120P	1200	13	0.63	12900	193	-	300	290	0.43	ISOPLUS247
IXFR26N120P	1200	15	0.55	14000	225	-	300	320	0.39	ISOPLUS247
IXFH16N120P	1200	16	0.95	6900	120	-	300	660	0.19	TO-247
IXFT16N120P	1200	16	0.95	6900	120	-	300	660	0.19	TO-268
IXFT16N120PHV	1200	16	0.95	6900	120	-	300	660	0.19	TO-268HV
IXFL30N120P	1200	18	0.38	19000	310	-	300	357	0.35	ISOPLUS i5-Pak?
IXFK20N120	1200	20	0.75	7400	160	-	300	780	0.16	TO-264
IXFX20N120	1200	20	0.75	7400	160	-	300	780	0.16	PLUS247
IXFX20N120P	1200	20	0.57	11100	193	-	300	780	0.16	PLUS247
IXFN20N120	1200	20	0.75	7400	160	-	300	780	0.16	SOT-227B
IXFN20N120P	1200	20	0.57	11100	193	-	300	595	0.21	SOT-227B
IXFK20N120P	1200	20	0.57	11100	193	-	300	780	0.16	TO-264
IXFN22N120	1200	22	0.55	8100	210	-	300	625	0.2	SOT-227B
IXFN26N120P	1200	23	0.5	14000	255	-	300	695	0.18	SOT-227B
IXFL32N120P	1200	24	0.34	21000	360	-	300	520	0.24	ISOPLUS i5-Pak
IXFK26N120P	1200	26	0.5	14000	255	-	300	960	0.13	TO-264
IXFX26N120P	1200	26	0.5	14000	255	-	300	960	0.13	PLUS247
IXFB30N120P	1200	30	0.35	22500	310	-	300	1250	0.1	PLUS264
IXFN30N120P	1200	30	0.35	19000	310	-	300	890	0.14	SOT-227B
IXFN32N120P	1200	32	0.31	21000	360	-	300	1000	0.125	SOT-227B
IXFN32N120	1200	32	0.35	15900	400	-	180	780	0.16	SOT-227B

日韩欧美多p乱免费视频_久久精品国产欧美日韩_岛国精品一区二区_国产一区二区三区久久久 - 78色淫网站女女免费
